Supermicro CSE-213AC-R1K23LPB Case CSE-213AC-R1K23LPB 2U 16x2.5 inch Hot-swap SAS/SATA E-ATX Brown Box

Form Factor
2U chassis supports for maximum motherboard sizes - 13.68" x 13", E-ATX 12" x 13", ATX 12" x 10" motherboards Processor Support
Dual and Single Intel and AMD processors Available Color
Black Expansion Slots
7 low-profile expansion slot(s) Drive Bays
16 x 2.5" hot-swap SAS3/SATA drive bay
1 x 5.25" drive bay Backplane
16-port 2U SAS3 12Gbps direct-attached backplane, support up to 16x 2.5-inch SAS3/SATA3 HDD/SSD Peripheral Drives
Optional 1 x slim DVD-ROM drive bay
Optional 2 x USB 2.0 ports
Optional 1 x COM port tray Front Panel
Buttons
Power On/Off button
System Reset Button
LEDs
2 Network Activity LEDs
HDD activity LED
Power Status LED
Power Fail LED
System Information LED Systems Cooling
Fans
3 x 80mm heavy duty fan(s) with PWM fan(s) speed control Operating Environment (System)
Operating Temperature Range
5^oC - 35^oC (41^oF - 95^oF)
Non-Operating Temperature Range
-40^oC - 70^oC (-40^oF - 158^oF)
Operating Relative Humidity Range
8% - 90% (non-condensing)
Non-Operating Relative Humidity Range
5% - 95% (non-condensing) Item Dimension (L"xW"xH")
39 x 29 x 11

Weight
90 lbs

Warranty Information
3 years
