CSE-116TQ-R700WB - Supermicro Case CSE-116TQ-R700WB 1U 10x2.5inch SAS/SATA 700W/750W 80PLUS GOLD Black Retail

Form Factor
1U chassis support for max. motherboard size - 12" x 13" E-ATX
Optimized for WIO (W series) motherboards

Processor Support
Supports dual Intel / AMD processors

Available Color
Black Expansion Slots
2x Full-height Expansion Slots (Riser Card Required)
1x Low-profile Expansion Slot (Riser Card Required)

Drive Bays
Hot-swap
10x Hot-swap 2.5" SAS / SATA HDD tray
SAS or enterprise SATA HDD only recommended SAS / SATA Backplane
1x 1U SAS / SATA backplane with SES2
BPN-SAS-116TQ Manual

Front Panel
Buttons
Power On/Off button
UID button
LEDs
Power status LED
HDD activity LED
2x Network activity LEDs
Universal Information (UID) LED System Cooling
Fans
4x 40x56mm Counter-rotating PWM fans (Opt. 2x fans for AOC cooling) Power Supply
700W/750W Redundant AC-DC high-efficiency power supply with PMBus and I2C
AC Voltage
700W: 100 - 140 V, 50-60 Hz, 8.5-6 Amp
750W: 180 - 240V, 60-50 Hz, 5-3.8 Amp
DC Output
+5V standby 3 Amp
DC Output
+12V 700W: 58 Amp at 100-140V
750W: 62 Amp at 180-240V
With Power Distributor +
5V: 25 Amp
+3.3V: 25 Amp
-12V: 0.6 Amp
Certification
80PLUS Gold Certified Regulatory (Power Supply)
Power Supply Safety / EMC
USA - UL listed, FCC
Canada - CUL listed
CCC Certification
EN 60950/IEC 60950-Compliant
Europe/CE Mark
Germany - TUV Certified Item Dimension (L"xW"xH"):
23.5 x 17.2 x 1.7

Weight:
40 lb

Warranty Information:
1 Year
