Technical Specifications
Compliant with 3G/HD/SD-SDI standard
Supports xvYCC, x.v.Color and Deep Color
Supports 4K at 60Hz YUV 4:4:4, 8-bit
Supports 4K at 60Hz YUV 4:2:0, 10-bit HDR
Video bandwidth:
Up to 2.97Gbps
Auto 3G/HD/SD detection
Supported video resolutions:
3G:
1080p 50 / 59.94 / 60 (YUV 4:2:2)
HD:
720p at 50/59.94/60Hz
1080i at 50/59.94/60Hz
1080p at 23.98/24/25/29.97/30Hz
SD:
NTSC at 59.94Hz
PAL at 50Hz
Cable equalization:
3G-SDI: up to 60m (190ft)
HD-SDI: up to 150m (500ft)
SD-SDI: up to 300m (1000ft)
Metal housing with wall mount design
Power consumption:
up to 10 watts
Product:
Color: Grey
Housing material: Metal
Connector:
1x BNC, SDI, Input
4x BNC, SDI, Output
1x Power jack
Power adapter:
Input: 100-240VAC, 50/60 Hz
Output: DC 5V/1A
UL Listed: E135856/Level:VI Environmental conditions:
Operating temperature: 32 to 104 degrees F
Storage temperature: -4 to 140 degrees F
Relative humidity: 20 to 90% RH (non-condensing)
TAA compliant
Certifications/Standards:
FCC, CE, RoHS
Item Dimension (L"xW"xH")
6 x 8 x 3
Weight
2.00 LB
Warranty Information
2 years
