Technical Specifications
HDMI input:
1x HDMI 19-pin male connector
Input video resolution:
3840x2160 at 60Hz, 3840x2160 at 30Hz, 1920x1080 at 60Hz, 1280x720 at 60Hz
USB connector:
Supply power, or plug into the base unit for pairing, or upgrade the dongle
LED ring indicator:
Solid green: Ready to mirror
Solid red: Mirroring
Flashing green: The dongle is initializing or waiting for user tostart and pairing/software upgrading
Network connectivity:
Wireless data rate: Up to 1200Mbps
Wireless transmission protocol: WIFI IEEE 802.11 a/g/n/ac
Frequency band: 2.4 GHz and 5 GHz
Product:
Color: Black
Housing material: ABS
Connectors:
1x HDMI 19-pin, male connector
1x USB 2.0 Type-A, male
1x Touch button
2x LED ring
Environmental conditions:
Operating temperature: 32 to 104 degrees F
Storage temperature: -4 to 140 degrees F
Relative humidity: 20 - 90% RH (non-condensing)
Certifications/Standards:
FCC, CE, RoHS
Item Dimension (L"x W"x H")
12 x 1 x 3
Weight
1.00 LB
Warranty Information
2 Years
