Technical Specifications
Compliant with HDMI 2.0 / DP 1.2 / HDCP 2.2 Resolution:
HDMI input:
up to 4K at 60Hz YUV 4:4:4, 4K at 60Hz 10-bit YUV 4:2:0 HDR
Mini DisplayPort input:
up to 4Kx2K at 60Hz YUV 4:4:4
USB-C input:
up to 4Kx2K at 60Hz YUV 4:4:4 HDMI Audio:
LPCM 7.1 audio, Dolby Atmos, DolbyTrueHD, Dolby Digital Plus, DTS:X, and DTS-HD Master Audio pass-through Input connector:
HDMI, Male
Mini DisplayPort, Male
USB Type-C, Male Output connector:
HDMI Type-A, Male
USB Type-A, Male, Power only Video resolution:
Up to 4K at 60Hz 8-bit YUV 4:4:4 / 10-bit YUV 4:2:0 HDR (HDMI input only) Cable length:
Input:
HDMI / Mini DP / USB-C: 1ft
Output:
HDMI: 9.8ft
USB Type-A: 5ft
Product:
Color:
Black
Housing material:
Plastic
ESD protection:
Human body model +/-15kV air-gap discharge and +/-8kV contact discharge Environmental conditions:
Operating temperature:
32 to 104 degrees F
Storage temperature:
-4 to 140 degrees F
Relative humidity:
10-90% RH (non-condensing) Certifications/Standards:
FCC, CE, RoHS Item Dimension (L"xW"xH")
4 x 1 x 6
Weight
1 lb
Warranty Information
3 years
