Technical Specifications
Compliant with HDMI 1.3 and HDCP 1.4
Maximum transfer rate: 10.2Gbps
Support KVM Function, remote control conveniently
Point to Point connection: up to 60m
Note :
Does not support connecting to Router or Switch
Distance:
Cat5e: up to 50m
Cat6: up to 60m
Supports 2-Ch PCM stereo audio
Resolution:
HDTV: 480p / 720p / 1080i / 1080p 60Hz
PC VESA: 640x480, 800x600, 1024x768, 1280x720, 1280x800, 1280x1024, 1440x900, 1680x1050, 1920x1080
Housing material: Metal
Transmitting unit (TX):
Connectors:
1x 19-pin HDMI, Type A, Female, Input
1x 19-pin HDMI, Type A, Female, Loop-out
1x 4-pin USB 2.0 Type-A, Female, connect to PC
1x 8-pin, RJ45, Output
1x Power jack
1x Reset button
Receiving unit (RX):
Connectors:
1x 19-pin HDMI, Type A, Female, Input
1x 19-pin HDMI, Type A, Female, Loop-out
1x 4-pin USB 2.0 Type-A, Female, connect to PC
1x 8-pin, RJ45, Output
1x Power jack
1x Reset button
Power adapter:
Input: 100-240V / 50-60Hz
Output: DC 5V/2A
UL listed: E335801 / Level: VI
Environmental conditions:
Operating temperature: 32 to 140 degrees F
Storage temperature: 14 to 158 degrees F
Relative humidity: 0% to 90% RH (non-condensing)
Certifications/Standards:
FCC, CE, RoHS
Item Dimension (L"xW"xH")
6 x 8 x 4
Weight
2.00 LB
Warranty Information
2 years
