Technical Specifications
Wireless technology:
5GHz
Supported topology:
Extender:
1 Transmitter (TX) to 1 Receiver (RX)
Splitter:
1 Transmitter (TX) to 2 Receivers (RX)
Additional Receiver unit, part CE-H24711-S1, sold separately
Video compression technology:
HDbitT
Compliant with HDMI 2.0 and HDCP 2.2
Resolution:
480p / 720p / 1080i / 1080p at 60Hz / 4Kx2K at 30Hz / 4Kx2K at 60Hz
Wireless transmission distance:
Up to 200 meters (light-of-sight maximum)
Note: The transmission distance will vary depending on building layout, electronic interference, walls and partitions, other environmental conditions, and may be much less than the maximum
HDMI cable length:
Up to 3 meters (Input and Output)
Audio:
2-Ch PCM stereo audio
IR frequency:
20KHz to 60KHz
Housing material:
Metal
Housing color:
Black
Product:
Transmitting unit (TX):
Connectors:
1x 19-pin HDMI, Type A, Female, Input
1x 3.5mm jack, IR Blaster
2x Antenna
1x Power jack
1x Reset button
Receiver unit (RX):
Connectors:
1x 19-pin HDMI, Type A, Female, Output
1x 3.5mm jack, IR Receiver
2x Antenna
1x Power jack
1x Reset button
Power adapter:
Input: 100-240V / 50-60Hz
Output: DC 5V/3.1A
UL Listed: E335801 / Class VI
Environmental conditions:
Operating temperature: 32 to 122 degrees F
Storage temperature: 14 to 158 degrees F
Relative humidity: 0% to 90% RH (non-condensing)
Certifications/Standards:
FCC, CE, RoHS
Item Dimension (L"xW"xH")
3 x 18 x 10
Weight
4.63 LB
Warranty Information
2 years
