CE-H24511-S1 - Siig AUDIO SUPPORT RECEIVES HDMI AUDIO AND VIDEO SIGNALS TRUE 4K PERFORMANCE POH UP T

- Supports Full HD 1080p at 60Hz, 3D, 4Kx2K
- Maximum transmission distance:
230ft (70m) at 1080p
131ft (40m) at 4Kx2K
- Video Bandwidth:
10.2Gbps
- HDMI 1.4 and HDCP 2.2 compliant
- Supports CEC/IR/RS232 pass-through
- Supports bi-directional PoH function
- Bi-directional RS232/IR control
- HDBaseT technology
- LED status indicators
- Metal housing
- Connectors:
1x 19-pin HDMI, Type-A, Female, Output
1x 8P8C RJ-45, HDBaseT signal, Input
1x 3-pin RS-232 Phoenix, Female
1x 3.5mm jack, IR Blaster
1x 3.5mm jack, IR Emitter
1x Power jack, Input
- Power adapter:
Input: 100-240V / 50-60Hz
Output: DC 24V/1.25A
Not necessary if Transmitter connects with power adapter
- Environmental conditions:
Operating temperature: 32 to 122 degrees F
Storage temperature: 14 to 140 degrees F
Relative humidity: 0% to 90% RH (non-condensing)
- Certifications/Standards:
FCC, CE, RoHS
Item Dimension(L inchxW inchxH inch)
7 x 8 x 5
Weight
3.00lb
Warranty Information
3 years
