Technical Specifications
- Fully compliant with the HDMI 1.4 and HDCP 2.2 specification
- Splits a single HDMI input to four HDBaseT outputs
- Video resolutions:
Up to 1080p at 60Hz
- Transmission distance:
Up to 492 ft (150m) at 1080p at 60Hz resolution
- Supports the Power over Cable (PoC) feature, allowing the HDBaseT receivers to be powered by the splitter over the Ethernet cables
- Supports bidirectional IR control, 20KHz - 60KHz
- Smart EDID management via 4-pin DIP switch
- Metal housing
- Product:
- HDBaseT Splitter (TX):
Color: Black
Connectors:
1x 3-pin DIP Switch, EDID value
1x 19-pin HDMI, Type A, Female, Input
1x 19-pin HDMI, Type A, Female, Output
4x 8P8C RJ-45, HDBaseT signal, Output
1x 3.5mm jack, IR, Input for IR receiver
1x 3.5mm jack, IR, Output for IR emitter
1x 4-pin DIP Switch, EDID Preset
1x 3-pin Phoenix connector, Remote
1x 3-pin Phoenix connector, Master
1x Power Jack
- HDBaseT Receiver unit (RX):
Color: Black
Connectors:
1x 19-pin HDMI, Type A, Female, Output
1x 8P8C, RJ45, HDBaseT signal, Input
1x 3.5mm jack, IR, Input IR receiver
1x 3.5mm jack, IR, Output IR emitter
1x 2-pin DIP Switch, Ctrl/Update
1x 3-pin Phoenix connector, RS-232
- Power adapter:
Input: 100-240VAC, 50/60 Hz
Output: DC 24V/2.71A
- Environmental conditions:
Operating temperature: 32 to 104 degrees F
Storage temperature: -4 to 140 degrees F
Relative humidity: 20 to 90% RH (non-condensing)
- Certifications/Standards:
FCC, CE, RoHS
Item Dimension(L inchxW inchxH inch)
8 x 12 x 8
Weight
7.50lb
Warranty Information
3 years
