Technical Specifications
Compatible with HDMI 1.4, HDCP 1.4 and CEC
Wireless frequency:
60GHz Latency:
0ms Bandwidth:
Up to 10.2Gbps Resolution:
480p / 720p / 1080i / 1080p / 3840x2160 at 30Hz Distance:
Up to 30m (98ft line of sight)
Note:
The transmission distance will vary depending on building layout, electronic interference, walls and partitions, other environmental conditions. Your actual transmission distance may be much less than the maximum distance HDMI cable length:
Up to 3 meters (Input and Output)
Supports Dolby, TrueHD, DTS-HD Master Audio and LPCM digital audio streams up to 7.1 Channels
Color:
Black and Silver
Housing:
Aluminum
Product:
Transmitting unit (TX):
1x, 19-pin, HDMI, Female, Input
1x, Power jack
1x, 5-Pin, Micro USB, Power input
Note: Do not connect the included power adapter and Micro USB port at the same time.
2x, LED indicators, Power and Data
1x, Reset button
Receiving unit (RX):
1x, 19-pin, HDMI, Female, Output
1x, Power jack
1x, 5-Pin, Micro USB, Power input
Note: Do not connect the included power adapter and Micro USB port at the same time
2x, LED indicators, Power and Data
1x, Reset button
Power adapter:
Input: AC 100-240V/50-60Hz
Output: DC 5V/1A
UL Listed: E335801 / Class VI
Environmental conditions:
Operating temperature: 32 to 104 degrees F
Storage temperature: -4 to 158 degrees F
Relative humidity: 0% to 90% RH (non-condensing)
Certifications/Standards:
FCC, CE, RoHS Item Dimension (L"xW"xH")
6 x 8 x 4
Weight
2.00 LB
Warranty Information
2 years
