Technical Specifications
- Chip:
IT6663FN
- Compliant with HDMI 2.0, HDCP 2.2
- Supports xvYCC, x.v.Color and Deep Color
- Supports 3840x2160 at 60Hz, YUV 4:4:4, 8bit
- Supports 3840x2160 at 60Hz HDR, YUV 4:2:0, 10bit
- Video bandwidth:
18Gbps (single-link 600MHz)
- Resolution support:
480p/720p/1080i/1080p/2160p at 60Hz, 4K HDR
- HDMI cable length:
3840x2160 at 60Hz: up to 10m (5m/In, 5m/Out)
1080p and 3840x2160 at 30Hz: up to 15m (5m/In, 10m/Out)
- Supports default EDID and EDID learning from display
- Built-in Micro USB port for power or firmware update
- Audio support:
Dolby Digital, DTS-HD and Dolby TrueHD audio
- LED indication for power and signal status
- ESD protection:
+/- 15kV Air
+/- 8kV Contact
- Product:
Color: Black
Housing material: Metal
Connector:
-1x 19-Pin, HDMI, Type A, Female, Input
-2x 19-Pin, HDMI, Type A, Female, Output
-1x 5-Pin, Micro-USB, Female, Power / Firmware update
-1x 2-Pin, Switch, EDID Management
- Environmental conditions:
Operating temperature: 32 to 104 degrees F
Storage temperature: -4 to 140 degrees F
Relative humidity: 20 to 90% RH (non-condensing)
- Certifications/Standards:
FCC, CE, RoHS
- TAA compliant
Item Dimension(L inchxW inchxH inch)
6 x 5 x 1
Weight
1.00lb
Warranty Information
3 years
