Technical Specifications
Chipset: IT6663FN+IT6664E HDMI 2.0 compliant HDCP 2.2 compliant Supports 4K2K at 60 4:4:4 8bit Supports HDR 4K2K at 60 4:2:0 10bit Supports xvYCC, x.v.Color and Deep Color Video bandwidth: 18Gbps (single-link 600MHz) Supports resolution down scaling from 4K to 1080p. See Notes below for limitations Maximum Resolution:
3840x2160 at 60Hz (YUV 4:4:4)
HDR 3840x2160 at 60Hz (YUV 4:2:0) Display Mode:
Mirror
Supports embedded EDID and EDID learning via rotary control switch Audio support:
Dolby Digital, DTS-HD and Dolby TrueHD audio ESD protection:
+/-15kV Air / +/-8kV Contact
LED indication for power and signal Supports cascading of multiple splitters for adding more displays, supports up to 10 layers Built-in firmware update mechanism (via Micro USB port) for expanding compatibility Sturdy metal housing provides durability and reduces EMI/RFI noise interference Color:
Black Housing Material:
Alminum Transmission distance (HDMI cable):
4K at 60Hz: Up to 10M (5m/In,5m/Out)
1080p and 4K at 30Hz: Up to 15M (5m/In,10m/Out)
