Technical Specifications
HDMI and HDCP compatible
Supported resolutions
480p/720p/1080i/1080p Transmission distance
up to 196ft (60m) HDMI cable distance
up to 2M (Input and output) Housing
Metal Transmitting unit (TX)
Input: 1x 19-pin HDMI, Type A, Female
Output: 1x 8-pin, RJ45 Receiving unit (RX)
Input: 1x 8-Pin, RJ45
Output: 1x 19-pin, HDMI, Type A, Female Power adapter
Input: 100-240VAC
Output: 5V DC, 1A Operating temperature
32 to 122 degrees F Storage temperature
-4 to 140 degrees F Relative humidity
< 80% RH (non-condensing) Certifications/Standards
FCC, CE, RoHS Package Contents
HDMI Extender over single Cat5e/6 - 196ft (TX and RX units)
Power adapter (2)
User Reference Guide Item Dimension (L inchxW inchxH inch)
3 x 8 x 6
Weight
1.00 lb
Warranty Information
2 years
