Technical Specifications
Chipset:
STDP2600 Compliant with DisplayPort 1.2a specifications for 1, 2, or 4 lanes Supports 5.4Gbps (HBR2), 2.7Gbps (HBR) and 1.62Gbps (RBR) link rates Video Bandwidth: up to 21.6Gbps Input Video signal: 3.3 volts DC coupled Input DDC signal: 5 volts PC VGA, SVGA, XGA, SXGA, and UXGA display modes HDTV: 480p, 576p, 720p, 1080i, 1080p, and 4Kx2K Video resolution:
800x600, 1024x768, 1280x1024, 1440x900, 1600x900, 1600x1200, 1680x1050, 1920x1080 60Hz, 1920x1200 60Hz, 2048x1152 60Hz, 2560x1440 60Hz, 2560x1600 60Hz, 3840x2160 30Hz Compatible 3D formats defined in DP 1.2 and HDMI 1.4 specifications Standalone HDCP repeater capability Product:
Color: Black
Housing: Metal Connector:
1x 19-pin, HDMI, Male, Input
1x 20-pin, DisplayPort, Female, Output
1x 5-pin Micro USB, Female, Power input Cable:
Connector: USB Type AM to Micro BM
Color: Black
Length: 1.57" (40cm) Certifications/Standards:
FCC, CE, RoHS Country of origin:
Taiwan Requirements
2.33GHz dual-core CPU system with 2GB RAM and an available HDMI output Package Contents
HDMI to DisplayPort 4K Ultra HD Active Adapter
USB Type A to Micro-B cable
Installation guide Weight
0.55
Item Dimension
1.50 x 8.63 x 6.31
Warranty Information
3 Years
