Technical Specifications
Compatible with DisplayPort 1.2 specification
Complies with HDCP 2.2 and 1.4 content protection
Resolution:
Up to 4Kx2K 60Hz YUV 4:4:4
Bandwidth:
Up to 21.6Gbps (5.4Gbps per channel)
Active Optical Cable technology:
4x Discrete Optical Channels, 10GHz, 850nm Cable outside diameter:
4.5mm OD
Wire gauge:
26AWG
Cable jacket:
PVC
Flame retardance: UL VW-1
Product:
Cable length: 60m (197ft)
DP connector housing material: Zinc alloy
Color: Black
Connectors:
1 x 20-Pin, DisplayPort, Latching, Male, Source
1 x 20-Pin, DisplayPort, Latching, Male, Display
Gold plated
Environmental conditions:
Operating temperature: 32 to 122 degrees F
Storage temperature: -10 to 158 degrees F
Humidity: < 5% to 85% (non-condensing)
Certifications/Standards:
FCC, CE, RoHS Item Dimension (L"x W"x H")
4 x 9 x 9
Weight
3.92 LB
Warranty Information
2 years
