CB-DP2211-S1 - Siig DISPLAYPORT OUTPUT SIIG ACTIVE FIBER OPTIC | Aztek Computers
29+Years
SKU: KAZL68V38F |  Mfg. Part: CB-DP2211-S1  | UPC: 662774043234  |  0 Reviews  |     Share

CB-DP2211-S1 - Siig DISPLAYPORT OUTPUT SIIG ACTIVE FIBER OPTIC CABLE - 20 PIN DISPLAYPORT LEFT CONNE

8 Available
Condition: New

$136.69  $184.53
Need 10+? Request a volume quote
 Free Shipping for this Item

Product Overview

1.2 BLACK CABLE

Expert Overview

The Siig CB-DP2211-S1 is an active fiber optic DisplayPort cable designed for transmitting high-resolution video and audio signals over extended distances. This cable is suitable for IT environments requiring reliable DisplayPort 1.2 connectivity beyond the typical limitations of copper cables. It supports resolutions up to 4Kx2K at 60Hz YUV 4:4:4 and a bandwidth of up to 21.6Gbps, utilizing four discrete optical channels. The active optical technology facilitates signal integrity over its 15-meter (49-foot) length, making it appropriate for conference rooms, digital signage, or workstation setups where source and display are separated by a significant distance. Compliance with HDCP 2.2 and 1.4 ensures compatibility with protected content. The cable features a 4.5mm OD PVC jacket, zinc alloy connector housings, and gold-plated latching DisplayPort male connectors for secure connections. It addresses the need for long-distance, high-bandwidth DisplayPort signal transmission in professional settings.

Technical Specifications

Compatible with DisplayPort 1.2 specification
Complies with HDCP 2.2 and 1.4 content protection
Resolution:
Up to 4Kx2K 60Hz YUV 4:4:4
Bandwidth:
Up to 21.6Gbps (5.4Gbps per channel)
Active Optical Cable technology:
4x Discrete Optical Channels, 10GHz, 850nm
Cable outside diameter:
4.5mm OD
Wire gauge:
26AWG
Cable jacket:
PVC
Flame retardance: UL VW-1
Product:
Cable length: 15m (49ft)
DP connector housing material: Zinc alloy
Color: Black
Connectors:
1 x 20-Pin, DisplayPort, Latching, Male, Source
1 x 20-Pin, DisplayPort, Latching, Male, Display
Gold plated
Environmental conditions:
Operating temperature: 32 to 122 degrees F
Storage temperature: -10 to 158 degrees F
Humidity: < 5% to 85% (non-condensing)
Certifications/Standards:
FCC, CE, RoHS
Item Dimension (L"x W"x H")
4 x 9 x 9
Weight
3.00 LB
Warranty Information
2 years

Product Details

  • Manufacturer:
  • Model Number:
  • ASIN:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • TAA Compliant:
  • Country of Origin:
  • Siig
  • CB-DP2211-S1
  • B07X1TVS5H
  • 662774043234
  • New
  • 1.48 lbs
  • 9 X 3 X 9
  • Aug 22, 2026
  • Jun 12, 2020
  • Yes
  • NN
Product Identifiers: Brand: Siig • Part #: CB-DP2211-S1 • UPC: 662774043234 • ASIN: B07X1TVS5H • Category: Optical Fiber Cables • TAA Compliant

Frequently Asked Questions

What DisplayPort specification does this cable support?

This cable is compatible with the DisplayPort 1.2 specification, supporting resolutions up to 4Kx2K at 60Hz YUV 4:4:4 and a bandwidth of up to 21.6Gbps.

What content protection standards are supported by this cable?

The cable complies with both HDCP 2.2 and HDCP 1.4 content protection standards, ensuring compatibility with protected digital content.

What is the maximum length of this active fiber optic cable?

This active fiber optic cable has a fixed length of 15 meters (49 feet), designed for extended-distance DisplayPort signal transmission.

What type of connectors does this cable use?

The cable features 20-pin, latching, male DisplayPort connectors on both ends, with gold plating and zinc alloy housings for durability and secure connections.
