Technical Specifications
Essentials
Product Collection: 8th Generation Intel Core i5 Processors
Code Name: Products formerly Coffee Lake
Vertical Segment: Desktop
Processor Number: i5-8500 Performance
Number of Cores: 6
Number of Threads: 6
Processor Base Frequency: 3.00 GHz
Cache: 9 MB
Bus Speed: 8 GT/s DMI3
TDP: 65 W Supplemental Information
Embedded Options Available: Yes Memory Specifications
Max Memory Size (dependent on memory type): 64 GB
Memory Types: DDR4-2400
Max Number of Memory Channels: 2
Max Memory Bandwidth: 41.6 GB/s
ECC Memory Supported: No Processor Graphics
Processor Graphics: Intel UHD Graphics 630
Graphics Base Frequency: 350 MHz
Graphics Max Dynamic Frequency: 1.10 GHz
Graphics Video Max Memory: 64 GB
4K Support: Yes, at 60Hz
Max Resolution (HDMI 1.4): 4096x2304 at 24Hz
Max Resolution (DP): 4096x2304 at 60Hz
Max Resolution (eDP - Integrated Flat Panel): 4096x2304 at 60Hz
DirectX Support: 12
OpenGL Support: 4.5
Intel Quick Sync Video: Yes
Intel InTru 3D Technology: Yes
Intel Clear Video HD Technology: Yes
Intel Clear Video Technology: Yes
Number of Displays Supported: 3
Device ID: 0x3E92 Expansion Options
Scalability: 1S Only
PCI Express Revision: 3.0
PCI Express Configurations: Up to 1x16, 2x8, 1x8+2x4
Max Number of PCI Express Lanes: 16 Package Specifications
Sockets Supported: FCLGA1151
Max CPU Configuration: 1
Thermal Solution Specification: PCG 2015C (65W)
TJUNCTION: 100oC
Low Halogen Options Available: See MDDS Advanced Technologies
Intel Optane Memory Supported: Yes
Intel Turbo Boost Technology: 2.0
Intel vPro Technology: Yes
Intel Hyper-Threading Technology: No
Intel Virtualization Technology (VT-x): Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel VT-x with Extended Page Tables (EPT):Yes
Intel TSX-NI: Yes
Intel 64: Yes
Instruction Set: 64-bit
Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2, Intel AVX2
Idle States: Yes
Enhanced Intel SpeedStep Technology: Yes
Thermal Monitoring Technologies: Yes
Intel Identity Protection Technology: Yes
Intel Stable Image Platform Program (SIPP): Yes Security and Reliability
Intel AES New Instructions: Yes
Secure Key: Yes
Intel Software Guard Extensions (Intel SGX): Yes
Intel Memory Protection Extensions (Intel MPX): Yes
Intel OS Guard: Yes
Intel Trusted Execution Technology: Yes
Execute Disable Bit: Yes
Intel Boot Guard: Yes Item Dimension ( L inch x W inch x H inch)
5 x 3 x 4 Weight
1.00 lb Warranty Information
3-year limited
