General InformationIntel Xeon Processor E3-1200 Product Family Intel Xeon Processor E3-1200 Product Family BriefServers based on the Intel Xeon processor E3-1200 product family give you smarter control of the things that matter to your businessIn an on-demand world, businesses of every size must be responsive. So ask yourself: Can you and your employees access the programs and files you need - anywhere and at any time? Can you expand your IT systems simply and cost-effectively to support more users, new applications, and growing storage needs? Is your business protected against catastrophic data loss and security breaches? If not, it's time to consider stepping up to a real server.Technical InformationProcessor Manufacturer: IntelProcessor Core: Quad-core (4 Core)Clock Speed: 3.80 GHzL2 Cache: 1 MBL3 Cache: 8 MB64-bit Processing: YesProcess Technology: 14 nmProcessor Socket: Socket H4 LGA-1151Display & GraphicsGraphics Controller Manufacturer: IntelGraphics Controller Model: HD Graphics P630Power DescriptionThermal Design Power: 73 WPhysical CharacteristicsWidth: 1.5"Depth: 1.5"
Technical Specifications
Essentials Vertical Segment: Server Processor Number: E3-1275V6 Performance number of Cores: 4 number of Threads: 8 Processor Base Frequency: 3.00 GHz Max Turbo Frequency: 3.50 GHz Cache: 8 MB Bus Speed: 8 GT/s DMI3 TDP: 73 W VID Voltage Range: 0.55V-1.52V Supplemental Information Embedded Options Available: Yes Conflict Free: Yes Memory Specifications Max Memory Size (dependent on memory type): 64 GB Memory Types: DDR4-2400, DDR3L-1866 Max number of Memory Channels: 2 Max Memory Bandwidth: 37.5 GB/s ECC Memory Supported: Yes Graphics Specifications Processor Graphics: Intel HD Graphics P630 Graphics Base Frequency: 350.00 GHz Graphics Max Dynamic Frequency: 1.15 GHz Graphics Video Max Memory: 1.7 GB Graphics Output: eDP/DP/HDMI/DVI 4K Support: Yes, at 60Hz Max Resolution (HDMI 1.4): 4096x2160 at 24Hz Max Resolution (DP): 4096x2304 at 60Hz Max Resolution (eDP - Integrated Flat Panel) : 4096x2304 at 60Hz Max Resolution (VGA) : N/A DirectX Support: 12 OpenGL Support: 4.4 Intel Quick Sync Video: Yes Intel InTru 3D Technology: Yes Intel Clear Video HD Technology: Yes Intel Clear Video Technology: Yes number of Displays Supported: 3 Device ID: 0x191D Expansion Options Scalability: 1S Only PCI Express Revision: 3.0 PCI Express Configurations: 1x16, 2x8. 1x8+2x4 Max number of PCI Express Lanes: 16 Package Specifications Sockets Supported: FCLGA1151 Max CPU Configuration: 1 Advanced Technologies Intel Optane Memory Supported: Yes Intel Turbo Boost Technology: 2.0 Intel vPro Technology: Yes Intel Hyper-Threading Technology: Yes Intel Virtualization Technology (VT-x) : Yes Intel Virtualization Technology for Directed I/O (VT-d) : Yes Intel VT-x with Extended Page Tables (EPT): Yes Intel TSX-NI: Yes Intel 64: Yes Instruction Set: 64-bit Instruction Set Extensions: SSE4.1/4.2, AVX 2.0 Idle States: Yes Enhanced Intel SpeedStep Technology: Yes Thermal Monitoring Technologies: Yes Intel Data Protection Technology Intel AES New Instructions: Yes Secure Key: Yes Intel Software Guard Extensions (Intel SGX) : Yes Intel Memory Protection Extensions (Intel MPX) : Yes Intel Platform Protection Technology OS Guard: Yes Trusted Execution Technology: Yes Execute Disable Bit : Yes Intel Device Protection Technology with Boot Guard: Yes Item Dimension (L inchxW inchxH inch) 5 X 4 X 3
