The processor supports up to 64 GiB of dual-channel DDR4-2400 ECC memory and incorporates Intel's HD Graphics P630 IGP operating at 350 MHz with a burst frequency of 1.15 GHz.
Technical Specifications
Essentials Vertical Segment: Server Processor Number: E3-1245V6 Performance number of Cores: 4 number of Threads: 8 Processor Base Frequency: 3.70 GHz Max Turbo Frequency: 4.10 GHz Cache: 8 MB Bus Speed: 8 GT/s DMI3 TDP: 73 W VID Voltage Range: 0.55V-1.52V Supplemental Information Embedded Options Available: No Conflict Free: Yes Memory Specifications Max Memory Size (dependent on memory type): 64 GB Memory Types: DDR4-2400, DDR3L-1866 Max number of Memory Channels: 2 Max Memory Bandwidth: 37.5 GB/s ECC Memory Supported: Yes Graphics Specifications Processor Graphics: Intel HD Graphics P630 Graphics Base Frequency: 350.00 GHz Graphics Max Dynamic Frequency: 1.15 GHz Graphics Video Max Memory: 1.7 GB Graphics Output: eDP/DP/HDMI/DVI 4K Support: Yes, at 60Hz Max Resolution (HDMI 1.4): 4096x2160 at 24Hz Max Resolution (DP): 4096x2304 at 60Hz Max Resolution (eDP - Integrated Flat Panel) : 4096x2304 at 60Hz Max Resolution (VGA) : N/A DirectX Support: 12 OpenGL Support: 4.4 Intel Quick Sync Video: Yes Intel InTru 3D Technology: Yes Intel Clear Video HD Technology: Yes Intel Clear Video Technology: Yes number of Displays Supported: 3 Device ID: 0x191D Expansion Options Scalability: 1S Only PCI Express Revision: 3.0 PCI Express Configurations: 1x16, 2x8. 1x8+2x4 Max number of PCI Express Lanes: 16 Package Specifications Sockets Supported: FCLGA1151 Max CPU Configuration: 1 Advanced Technologies Intel Optane Memory Supported: Yes Intel Turbo Boost Technology: 2.0 Intel vPro Technology: Yes Intel Hyper-Threading Technology: Yes Intel Virtualization Technology (VT-x) : Yes Intel Virtualization Technology for Directed I/O (VT-d) : Yes Intel VT-x with Extended Page Tables (EPT): Yes Intel TSX-NI: Yes Intel 64: Yes Instruction Set: 64-bit Instruction Set Extensions: SSE4.1/4.2, AVX 2.0 Idle States: Yes Enhanced Intel SpeedStep Technology: Yes Thermal Monitoring Technologies: Yes Intel Data Protection Technology Intel AES New Instructions: Yes Secure Key: Yes Intel Software Guard Extensions (Intel SGX) : Yes Intel Memory Protection Extensions (Intel MPX) : Yes Intel Platform Protection Technology OS Guard: Yes Trusted Execution Technology: Yes Execute Disable Bit : Yes Intel Device Protection Technology with Boot Guard: Yes Item Dimension (L inchxW inchxH inch) 5 X 4 X 3
