Take on monstrous computing demands with the Intel Xeon E5-2697 v4 Octadeca-core (18 Core) 2.30 GHz 64-Bit Processor - Socket R3 (LGA2011-3) Retail Pack BX80660E52697V4. This advanced system is meant for things like video rendering, data processing and other large-scale computer tasks. The 18-core processor is designed with a 45MB cache for effective management tasks. It's based on the 14nm architecture, making it highly efficient and compact for its overall power. This Intel Xeon processor requires a total of 145W of power and it's an excellent addition to any large-sized data center. The unit slots into a standard R3 socket, making it compatible with a large amount of equipment available today.
Technical Specifications
Processor Number E5-2697V4 Performance Number of Cores: 18 Number of Threads: 36 Processor Base Frequency: 2.30 GHz Max Turbo Frequency: 3.60 GHz Cache: 45 MB SmartCache Bus Speed: 9.6 GT/s QPI Number of QPI Links: 2 TDP: 145 W VID Voltage Range: 0 Supplemental Information Embedded Options Available: No Conflict Free: Yes Memory Specifications Max Memory Size (dependent on memory type): 1.54 TB Memory Types: DDR4 1600/1866/2133/2400 Max Number of Memory Channels: 4 Max Memory Bandwidth: 76.8 GB/s Physical Address Extensions: 46-bit ECC Memory Supported: Yes Graphics Specifications Processor Graphics: None Expansion Options Scalability: 2S PCI Express Revision: 3.0 PCI Express Configurations: x4, x8, x16 Max Number of PCI Express Lanes: 40 Package Specifications Sockets Supported: FCLGA2011-3 Max CPU Configuration: 2 TCASE: 79oC Low Halogen Options Available: See MDDS Advanced Technologies Intel Turbo Boost Technology: 2.0 Intel vPro Technology: Yes Intel Hyper-Threading Technology : Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) : Yes Intel VT-x with Extended Page Tables (EPT) : Yes Intel TSX-NI Yes Intel 64: Yes Instruction Set : 64-bit Instruction Set Extensions: AVX 2.0 Idle States: Yes Enhanced Intel SpeedStep Technology : Yes Intel Demand Based Switching : Yes Thermal Monitoring Technologies: Yes Intel Flex Memory Access: No Intel Identity Protection Technology: No Intel Data Protection Technology Intel AES New Instructions : Yes Secure Key: Yes Intel Platform Protection Technology OS Guard : Yes Trusted Execution Technology: Yes Execute Disable Bit : Yes Item Dimension (L inchxW inchxH inch) 4 x 5 x 2
Weight 1.00 lb
Warranty Information Warranty Intel 3-Year Limited
Product Details
Manufacturer:
Model Number:
ASIN:
Condition:
Weight:
Dimensions:
Updated:
Added:
Intel
BX80660E52697V4
B01CNKF3A6
New
1 lbs
2 X 2 X 2
Feb 19, 2026
Dec 23, 2016
Product Identifiers:
Brand: Intel •
Part #: BX80660E52697V4 • ASIN: B01CNKF3A6 • Category: Server CPUs/Processors
