The IntelNUC built with 5th generation Intel Core processors takes the powerful capabilities of a complete desktop system and packages it into 4 small inches. Get premium performance, eye-popping visuals, and home theater features that give you the power to play, create, entertain, and inspire right from your home. And with a replaceable lid, you can customize your NUC to deliver the style and features that fit your life. The Intel NUC gives you the power you need-and doesn't require more than 4 inches of real estate, whether in your living room, den, or office. Discover what's possible with an Intel NUC.
Technical Specifications
Code Name Baby Canyon Essentials Status:Launched Launch Date:Q117 Board Form Factor:UCFF (4" x 4") Socket:Soldered-down BGA Internal Drive Form Factor: M.2 SSD Number of Internal Drives Supported:1 Lithography:14 nm TDP:15 W DC Input Voltage Supported:12-19 VDC Processor Included:Intel Core i5-7260U Processor (4M Cache, up to 3.40 GHz) Memory Storage Max Memory Size (dependent on memory type):32 GB Memory Types:DDR4-2133 1.2V SO-DIMM Max Number of Memory Channels:2 Max Memory Bandwidth:34.1 GB/s Max Number of DIMMs:2 ECC Memory Supported:No Processor Graphics Integrated Graphics:Yes Graphics Output:HDMI 2.0a USB-C (DP1.2) Number of Displays Supported:3 Expansion Options PCI Express Revision:Gen3 PCI Express Configurations:M.2 slot with PCIe x4 lanes Removable Memory Card Slot:SDXC with UHS-I support M.2 Card Slot (storage):22x42/80 I/O Specifications Number of USB Ports:6 USB Configuration:2x front and 2x rear USB 3.0 2x USB 2.0 via internal headers USB Revision:2.0, 3.0 USB 2.0 Configuration (External + Internal):0 + 2 USB 3.0 Configuration (External + Internal):2B 2F + 0 Total Number of SATA Ports:2 Max Number of SATA 6.0 Gb/s Ports:2 RAID Configuration: N/A Audio (back channel + front channel):7.1 digital (HDMI mDP) L+R+mic (F) Integrated LAN:10/100/1000 Integrated Wireless:Intel Wireless-AC 8265 + Bluetooth 4.2 Integrated Bluetooth:Yes Consumer Infrared Rx Sensor:Yes Additional Headers:CEC, 2x USB2.0, FRONT_PANEL Number of Thunderbolt 3 Ports:1 Item Dimension (L inchxW inchxH inch) 16 x 8 x 4 Weight 4.00lb Warranty Information 3-year limited
