BOXDP55WB - Intel MINI ATX MOTHERBOARD S1156 DDR3 14 USB HARD DRIVE AUDIO GIG ETHERNET

MATX MBD S1156 DDR3 14 USB HD AUD GETH
With the Intel Desktop Board DP55WB you can cash in on an affordable board solution while exploring new levels of performance with the Intel Core i7 and Intel Core i5 processors. This board has a micro-ATX form factor and loads of expansion capabilities - PCI Express 2.0 x16 slot, 4 DIMMs slots for DDR3 memory, and eight back panel USB 2.0 ports - allowing for one feature-rich system.
Product Description Intel Desktop Board DP55WB Media Series - motherboard - micro ATX - iP55
Product Type Motherboard
Form Factor Micro ATX
Dimensions (WxDxH) 9.6 in x 9.6 in
Chipset Type Intel P55 Express
Multi-Core Support Quad-core
Processor 0 ( 1 ) - LGA1156 Socket
Compatible Processors Core i5, Core i7
64-bit Processors Compatibility Yes
RAM 0 MB (installed) / 16 GB (max)
Supported RAM Technology DDR3 SDRAM
Supported RAM Integrity Check Non-ECC
Storage Controller Serial ATA-300 (RAID)
USB Ports Configuration 14 x USB
Storage Ports Configuration 6 x SATA
FireWire Ports Configuration 1 x FireWire
Audio Output Sound card
Networking Network adapter - Ethernet, Fast Ethernet, Gigabit Ethernet
Microsoft Certification Compatible with Windows 7
Manufacturer Warranty 3 years warranty
General
Product Type Motherboard
Form Factor Micro ATX
Width 9.6 in
Depth 9.6 in
Compatible Processors Core i5, Core i7
64-bit Processors Compatibility Yes
Processor Socket LGA1156 Socket
Multi-Core Support Quad-core
Chipset Type Intel P55 Express
BIOS Type Intel
Storage Controller Serial ATA-300 (RAID)
Power Connectors 24-pin main power connector, 8-pin ATX12V connector
Processor
Installed Qty (Max Supported) 0 ( 1 )
Memory
Supported RAM Technology DDR3 SDRAM
Supported RAM Integrity Check Non-ECC
RAM Installed ( Max ) 0 MB / 16 GB (max)
Supported RAM Speed PC3-8500, PC3-10666
RAM Features Unbuffered, unregistered, dual channel memory architecture
Audio
Audio Output Sound card
Audio Codec Realtek ALC888
Compliant Standards High Definition Audio
Telecom / Networking
Networking Network adapter - Ethernet, Fast Ethernet, Gigabit Ethernet
Features
BIOS Features Rapid BIOS boot, WfM 2.0 support, ACPI 3.0b support, DMI 2.5 support
Hardware Monitoring CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU core voltage
Sleep / Wake Up Keyboard wake up, suspend to RAM (STR), mouse wake up, wake on PCI device, wake on USB port
Hardware Features Chassis intrusion detection, Intel Turbo Boost Technology
Expansion / Connectivity
Expansion Slot(s)[ processor - LGA1156 Socket 4 memory - DIMM 240-pin 1 PCI Express 2.0 x16 2 PCI Express 2.0 x1 1 PCI
Storage Interfaces Serial ATA-300 - connector(s): 6 x 7pin Serial ATA - 6 device(s) - RAID 0 / RAID 1 / RAID 10 / RAID 5
Interfacesb x Hi-Speed USB - 4 pin USB Type A 1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 1 x audio - line-out - mini-phone stereo 3.5 mm 1 x audio - line-in - mini-phone stereo 3.5 mm 1 x microphone - input - mini-phone 3.5 mm
Additional Connectors (Optional) 1 x IEEE 1394 (FireWire), 6 x Hi-Speed USB
Miscellaneous
Included Accessories I/O back plate
Software Included Intel Express Installer
Compatible with Windows 7 "Compatible with Windows 7" software and devices carry Microsoft’s assurance that thes
