BKNUC8CCHB - Intel BTO NUC

Essentials
Product Collection
Intel NUC Board with Intel Celeron Processors
Code Name
Intel NUC Board NUC8CCHB
Status
Launched
Supported Operating Systems
Windows 10, 64-bit
Board Number
NUC8CCHB
Board Form Factor
3.5" SBC (146mm x 101.6mm)
Internal Drive Form Factor
M.2 SSD
Embedded Storage
64 GB
Off Roadmap
No
DC Input Voltage Supported
12V - 24V
Processor Included
Intel Celeron Processor N3350 (2M Cache, up to 2.4 GHz)
Number of Cores
2
Number of Threads
2
Processor Base Frequency
1.10 GHz
Recommended Customer Price
190.90 dollars
Supplemental Information
Embedded Options Available
No
Memory and Storage
Included Storage
64GB eMMC
Included Memory
4GB LPDDR3 (dual-channel, soldered-down)
ECC Memory Supported
No
Processor Graphics
Processor Graphics
Intel HD Graphics 500
Graphics Output
HDMI 2.0, HDMI 1.4, 4-lane eDP 1.4
Number of Displays Supported
2
Expansion Options
PCI Express Revision
Gen 2
M.2 Card Slot (wireless)
22x30 slot (key E)
M.2 Card Slot (storage)
22x80 slot (key M,NVMe/SATA)
I/O Specifications
Number of USB Ports
4
USB Configuration
1x front and 1x rear USB 3.0,
2x rear USB 2.0,
1x USB 3.0 and 2x USB 2.0 via internal headers
Serial Port via Internal Header
Yes
Audio (back channel + front channel)
1/8" line out
Integrated LAN
Intel i211-AT (10/100/1000 Mbps)
Additional Headers
Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby),Internal 2x2 power connector
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
TPM
No
Intel HD Audio Technology
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Platform Trust Technology (Intel PTT)
Yes
Security and Reliability
Intel AES New Instructions
Yes
Intel Trusted Execution Technology
No
Item Dimension (L"xW"xH")
10 x 7 x 8
Weight
5.00 LB
Warranty Information
3-year limited
