B7119F77V14HR-2T-N - Tyan System B7119F77V14HR-2T-N 4U Rackmount Dual Socket Xeon 14x2.5 SATA 6GB Hotswap Brown Box

System
Form Factor : 4U Rackmount
Chassis Model : FA77
Motherboard Name : S7119GMRE Front Panel
Buttons: (1) RST / (1) NMI / (1) ID / (1) PWR w/ LED
LEDs : (1) HDD / (1) ID / (1) Warning / (3) LAN
I/O Ports : (1) VGA port / (2) USB 3.0 ports / (1) COM Port Internal Drive Bay
Type / Qty : 2.5" Hot-Swap SSD/HDD/ (14)
HDD Backplane Support: SAS 12Gb/s /SATA 6Gb/s
Supported HDD Interface : (14) SATA 6Gb/s System Cooling Configuration
Redundancy : Yes
FAN : (5+1) hot-swap 12cm fans Power Supply
Type : RPSU
Input Range : AC 100-127V/12A / AC 200-240V/9.48A
Frequency : 47-63 Hz
Output Watts : 3,000 Watts (100-127Vac input) / 4,800Watts (200-240Vac input)
Efficiency : PFC / 80 plus Platinum
Redundancy : 3+1 Processor
Qty / Socket Type : (2) LGA3647
Supported CPU Series : Intel Xeon Scalable Processor
Thermal Design Power (TDP) Wattage : Max up to 205W
System Bus : Up to 10.4/9.6 GT/s with Intel UltraPath Interconnect (UPI) support Chipset
PCH : Intel C621
Switch IC : (2) PLX PEX8796 Memory
Supported DIMM Qty : (12)+(12) DIMM slots
DIMM Type / Speed : DDR4 RDIMM/RDIMM 3DS/LRDIMM/LRDIMM 3DS 2666
Capacity : Up to 768GB RDIMM/ 1,536GB LRDIMM/ 3,072GB RDIMM 3DS/LRDIMM 3DS -Follow latest Intel DDR4 Memory POR
Memory channel : 6 Channels per CPU
Memory voltage : 1.2V Expansion Slots
PCI-E : (1) PCI-E Gen3 x16 Tyan Mezzanine slot / (1) PCI-E Gen3 x16 slot (Full-height, Full-length, Single-width) / (1) PCI-E Gen3 x16 OCP 2.0 slot (conn.A+conn.B) / (10) PCI-E Gen3 x16 slots (Full-height, Full-length, Double-width)
Pre-install TYAN Riser Card : (1) M2217-L16-IO riser card for (1) storage mezz. slot LAN
Qty / Port : (2) 10GbE ports, (1) GbE port dedicated for IPMI
Controller : Intel X540-BT2
PHY : Realtek RTL8211E Storage
SATA
Connector : (2) Mini-SAS HD (8-ports)
Controller : Intel C621
Speed : 6.0 Gb/s
RAID : RAID 0/1/10/5 (Intel RSTe)
sSATA
Connector : (2) SATA-III / (1) Mini-SAS HD (4-ports)
Controller : Intel C621
Speed : 6.0 Gb/s
RAID : RAID 0/1/10/5 (Intel RSTe) Graphic
Connector type : D-Sub 15-pin
Resolution : Up to 1920x1200
Chipset: Aspeed AST2500 I/O Ports
USB : (2) USB3.0 ports (at rear) / (2) USB3.0 ports (at front)
COM : (1) DB-9 COM port (at front)
VGA : (1) D-Sub 15-pin port (at front)
RJ-45 : (2) 10GbE ports, (1) GbE dedicated for IPMI TPM (Optional)
TPM Support : Please refer to our TPM supported list. System Monitoring
ChipsetAspeed : AST2500
Temperature : Monitors temperature for CPU and memory and system environment
Voltage :Monitors voltage for CPU, memory, chipset and power supply
LED : Over temperature warning indicator / Fan and PSU fail LED indicator
Others : Watchdog timer support Server Management
Onboard Chipset : Onboard Aspeed AST2500
AST2500 iKVM Feature : 24-bit high quality video compression / Supports storage over IP and remote platform-flash / USB 2.0 virtual hub
AST2500 IPMI Feature : IPMI 2.0 compliant baseboard management controller (BMC) / 10/100/1000 Mb/s MAC interface BIOS
Brand / ROM size : AMI / 32MB
Feature: Hardware Monitor / SMBIOS 3.0/PnP/Wake on LAN / Boot from USB device/PXE via LAN/Storage / User Configurable FAN PWM Duty Cycle / Console Redirection / ACPI sleeping states S4,S5 / ACPI 6.1 Operating System
OS supported list : Please refer to our AVL support lists. Regulation
FCC (SDoC) : Class A
CE (DoC) : Class A
CB/LVD : Yes
RCM : Class A
VCCI : Class A Operating Environment
Operating Temp. : 10^o C to 35^o C (50^o Fto 95^o F)
Non-operating Temp. : - 40^o C to 70^o C (-40^o F to 158^o F)
In/Non-operating Humidity : 90%, non-condensing at 35^o C
Note : Please refer to the TYAN NVIDIA Compatibility List for the operating temperature while GPGPU deployed
