Technical Specifications
System: 1U RackmountChassis Model: GT62HMotherboard Name: S7106GM2NR-10EFront Panel: (1) PWR / (1) RST / (1) IDI/O Ports: (2) USB 3.0 portsExternal Drive Bay: (10) NVMeSystem Cooling Configuration: (6) 4cm fansPower Supply: RPSU, 800 Watts, 80 plus Platinum, 1+1 Redundancy, Hot-swapProcessor: (2) LGA3647, Intel Xeon Scalable Processor, Max TDP up to 165WMemory: Up to 512GB RDIMM / 1,024GB LRDIMM / 768GB LRDIMM 3DS, DDR4 2666Expansion Slots: (2) PCI-E Gen3 x16 slots, Pre-install TYAN Riser Card, Pre-install TYAN Mezz CardLAN: (2) GbE ports, Intel I210-AT Controller, Realtek RTL8211E PHYStorage: sSATA, Intel C621 Controller, RAID 0/1/10/5 (Intel RSTe), (10) NVMe ports, (1) M.2 portGraphic: Aspeed AST2500 Chipset, D-Sub 15-pin ConnectorI/O Ports: USB, COM, VGA, RJ-45, TPM SupportSystem Monitoring: Aspeed AST2500 Chipset, Temperature and Voltage Monitoring, Watchdog Timer, LED IndicatorsServer Management: Onboard Aspeed AST2500 Chipset, iKVM and IPMI Features, BIOS featuresOperating System: OS supported list, Regulation: FCC (DoC), CE (DoC), CB/LVD, RCM, VCCIOperating Environment: Operating Temp: 10°C to 35°C, Non-operating Temp: -40°C to 70°C, Humidity: 90% non-condensing at 35°C
