Technical Specifications
System
Form Factor : 1U Rackmount
Chassis Model : GT24E
Motherboard Name : S7106GM2NR Front Panel
Buttons: (1) RST / (1) NMI / (1) PWR w/ LED / (1) UID
LEDs : (1) ID / (1) UID / (1) BMC event
I/O Ports : (2) USB 3.0 ports External Drive Bay
Type / Qty : 3.5"/2.5" Hot-Swap / (4)
HDD Backplane Support : SAS 12Gb/s /SATA 6Gb/s
Supported HDD Interface : (4) SATA 6Gb/s Internal Drive Bay
Type / Qty : (2) 2.5" fixed SSD (with height up to 9.5mm)
Supported HDD Interface : (2) SATA 6Gb/s System Cooling Configuration
FAN : (6) 4cm fans Power Supply
Type : RPSU
Input Range : AC 100-240V/9A
Frequency : 50-60 Hz
Output Watts : 650 Watts
Efficiency : 80-plus
Redundancy : 1+1
Serviceability : Hot-swap Processor
Qty / Socket Type : (2) LGA3647
Supported CPU Series : Intel Xeon Scalable Processor
Thermal Design Power (TDP) Wattage : Max up to 165W
System Bus : Up to 10.4/9.6 GT/s with Intel UltraPath Interconnect (UPI) support Chipset
PCH : Intel C621 Memory
Supported DIMM Qty : (8)+(8) DIMM slots
DIMM Type / Speed : DDR4 RDIMM/RDIMM 3DS/LRDIMM/LRDIMM 3DS 2666
Capacity : Up to 512GB RDIMM/ 1,024GB LRDIMM/ 768GB LRDIMM 3DS Follow latest Intel DDR4 Memory POR
Memory channel : 6 Channels per CPU
Memory voltage : 1.2V Expansion Slots
PCI-E : (1) PCI-E Gen3 x16 Tyan Mezzanine slot / (2) PCI-E Gen3 x16 slots (Full-height, Half-length) / (1) PCI-E Gen3 x16 OCP 2.0 slot (conn.A+conn.B)
Pre-install TYAN Riser Card : (1) M7106-L16-1F for (1) PCI-E Gen3 x16 slot / (1) M7106-R16-1F riser card for (1) PCI-E Gen3 x16 slot LAN
Qty / Port : (2) GbE ports / (1) PHY
Controller : Intel I210-AT
PHY : Realtek RTL8211E Storage
SATA
Connector : (2) Mini-SAS HD (8-ports)
Controller : Intel C621
Speed : 6.0 Gb/s
RAID : RAID 0/1/10/5 (Intel RSTe)
sSATA
Connector : (2) SATA-III / (1) Mini-SAS HD (4-ports)
Controller : Intel C621
Speed : 6.0 Gb/s
RAID : RAID 0/1/10/5 (Intel RSTe)
M.2 connector : (1) M.2 connector (2280/2260/2242) by PCI-E interface Graphic
Connector type : D-Sub 15-pin
Resolution : Up to 1920x1200
Chipset : Aspeed AST2500 I/O Ports
USB : (2) USB3.0 ports (at rear) / (2) USB3.0 ports (at front)
COM : (1) DB-9 COM port
VGA : (1) D-Sub 15-pin port
RJ-45 : (2) GbE ports, (1) GbE dedicated for IPMI TPM (Optional)
TPM Support : Please refer to our TPM supported list. System Monitoring
Chipset : Aspeed AST2500
Temperature : Monitors temperature for CPU and memory and system environment
Voltage: Monitors voltage for CPU, memory, chipset and power supply
LED : Over temperature warning indicator / Fan and PSU fail LED indicator
Others : Watchdog timer support Server Management
Onboard Chipset : Onboard Aspeed AST2500
AST2500 iKVM Feature : 24-bit high quality video compression / Supports storage over IP and remote platform-flash / USB 2.0 virtual hub
AST2500 IPMI Feature : IPMI 2.0 compliant baseboard management controller (BMC) / 10/100/1000 Mb/s MAC interface BIOS
Brand / ROM size : AMI / 32MB
Feature: Hardware Monitor / SMBIOS 3.0/PnP/Wake on LAN / Boot from USB device/PXE via LAN/Storage / User Configurable FAN PWM Duty Cycle / Console Redirection / ACPI sleeping states S4,S5 / ACPI 6.1 Operating System
OS supported list : Please refer to our AVL support lists. Regulation
FCC (DoC) : Class A
CE (DoC) : Class A
CB/LVD: Yes
RCM : Class A
VCCI : Class A
