B7106G24EV2E2HR - Tyan System B7106G24EV2E2HR 1U RM Dual Socket Xeon 4x3.5 inch HS 2x2.5 inch Brown Box

System
Form Factor
1U Rackmount
Chassis Model
GT24E
Motherboard Name
S7106GM2NR
Front Panel
Buttons
(1) RST / (1) NMI / (1) PWR w/ LED / (1) UID
LEDs
(1) ID / (1) UID / (1) BMC event
I/O Ports
(2) USB 3.0 ports
External Drive Bay
Qty / Type
(2) 3.5"/2.5" Hot-Swap SSD/HDD + (2) NVMe
HDD Backplane Support
SAS 12Gb/s /SATA 6Gb/s / NVMe
Supported HDD Interface
(2) SATA 6Gb/s + (2) NVMe
Internal Drive Bay
Type / Qty
(2) 2.5" fixed SSD (with height up to 9.5mm)
Supported HDD Interface
(2) SATA 6Gb/s
System Cooling Configuration
FAN
(6) 4cm fans
Power Supply
Type
RPSU
Input Range
AC 100-240V/9A
Frequency
50-60 Hz
Output Watts
650 Watts
Efficiency
80-plus
Redundancy
1+1
Serviceability
Hot-swap
Processor
Qty / Socket Type
(2) LGA3647
Supported CPU Series
Intel Xeon Scalable Processor
Thermal Design Power (TDP) Wattage
Max up to 165W
System Bus
Up to 10.4/9.6 GT/s with Intel UltraPath Interconnect (UPI) support
Chipset
PCH
Intel C621
Memory
Supported DIMM Qty
(8)+(8) DIMM slots
DIMM Type / Speed
DDR4 RDIMM/RDIMM 3DS/LRDIMM/LRDIMM 3DS 2666
Capacity
Up to 512GB RDIMM/ 1,024GB LRDIMM/ 768GB LRDIMM 3DS (Follow latest Intel DDR4 Memory POR)
Memory channel
6 Channels per CPU
Memory voltage
1.2V
Expansion Slots
PCI-E
(2) PCI-E Gen3 x16 slots (Full-height, Half-length) / (1) PCI-E Gen3 x16 OCP 2.0 slot (conn.A+conn.B) / (1) PCI-E Gen3 x16 storage mezz. slot
Pre-install TYAN Riser Card
(1) M7106-L16-1F for (1) PCI-E Gen3 x16 slot / (1) M7106-R16-1F riser card for (1) PCI-E Gen3 x16 slot
Pre-install TYAN Mezz Card
M7106-4E w/ (2) OCulink 8x connectors for (4) NVMe ports
LAN
Qty / Port
(2) GbE ports / (1) PHY
Controller
Intel I210-AT
PHY
Realtek RTL8211E
Storage
SATA
NVMe:(4) NVMe ports default from 1x M7106-4E card
Connector:(2) Mini-SAS HD (8-ports)
Controller:Intel C621
Speed:6.0 Gb/s
RAID:RAID 0/1/10/5 (Intel RSTe)
sSATA
Connector:(2) SATA-III / (1) Mini-SAS HD (4-ports)
Controller:Intel C621
Speed:6.0 Gb/s
RAID:RAID 0/1/10/5 (Intel RSTe)
M.2 connector:(1) M.2 connector (2280/2260/2242) by PCI-E interface
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500
I/O Ports
USB
(2) USB3.0 ports (at rear) / (2) USB3.0 ports (at front)
COM
(1) DB-9 COM port
VGA
(1) D-Sub 15-pin port
RJ-45
(2) GbE ports, (1) GbE dedicated for IPMI
TPM (Optional)
TPM Support
Please refer to our TPM supported list.
System Monitoring
Chipset
Aspeed AST2500
Temperature
Monitors temperature for CPU memory system environment
Voltage
Monitors voltage for CPU, memory, chipset power supply
LED
Over temperature warning indicator / Fan PSU fail LED indicator
Others
Watchdog timer support
Server Management
Onboard Chipset
Onboard Aspeed AST2500
AST2500 iKVM Feature
24-bit high quality video compression / Supports storage over IP and remote platform-flash / USB 2.0 virtual hub
AST2500 IPMI Feature
IPMI 2.0 compliant baseboard management controller (BMC) / 10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size
AMI / 32MB
Feature
Hardware Monitor / SMBIOS 3.0/PnP/Wake on LAN / Boot from USB device/PXE via LAN/Storage / User Configurable FAN PWM Duty Cycle / Console Redirection / ACPI sleeping states S4,S5 / ACPI 6.1
Operating System
OS supported list
Please refer to our AVL support lists.
Regulation
FCC (DoC)
Class A
CE (DoC)
Class A
CB/LVD
Yes
RCM
Class A
VCCI
Class A
Operating Environment
Operating Temp.
10^o C - 35^o C (50^o F- 95^o F)
Non-operating Temp.
- 40^o C - 70^o C (-40^o F - 158^o F)
In/Non-operating Humidity
90%, non-condensing at 35^o C
