Technical Specifications
Essentials
Product Collection
Intel Wireless Products
Code Name
Products formerly Cyclone Peak
Operating Temperature Range
0oC to 80oC
Supported Operating Systems
Windows 10, 64-bit, Google Chrome OS, Linux
Antenna
2x2 Networking Specifications
TX/RX Streams
2x2
Bands
2.4Ghz, 5Ghz (160Mhz)
Max Speed
2.4Gbps
Wi-Fi CERTIFIED
802.11ac WiFi 6 pre certified
Compliance
FIPS, FISMA
Bluetooth Version
5
Integrated Bluetooth
Yes Package Specifications
Board Form Factor
M.2 2230, M.2 1216
Package Size
22mm x 30mm x 2.4mm, 12mm x 16mm x 1.65mm
System Interface Type
Wi-Fi(PCIe), BT(USB) Advanced Technologies
MU-MIMO
Yes
Supported Under Intel vPro Technology
Yes
Orthogonal Frequency-Division Multiple Access (OFDMA)
Yes Item Dimension (L"xW"xH")
11 x 9 x 2
Weight
5.95 lbs
Warranty Information
3 Year Standard
