Technical Specifications
General Specifications:
Cooling Fan(s)
Single, 120mm PWM Controlled FDB Fan Total Power Output
600W Total Continuous Output at 40C Output Connectors
Main 24Pin, (1)4+4 Pin, (2)PCI-E 6+2Pin, (5)SATA, (3)Molex 4-Pin, (1)FDD 4-Pin NVIDIA SLI Support
Yes AMD/ATI CrossFire Support
Yes 80PLUS Certified
Yes Modular Cable
N/A Safety Approvals
CB, CE, UL, FCC, TUV, GOST, CCC, BSMI MTBF
100,000 Hours Typical Input Specifications
- Input Voltage: 100V AC to 240V AC, 50 60Hz
- Power Factor Correction (PFC): Active PFC >99% Input Current
6.0A at 100 Vrms, 60 Hz
- 3.0A at 240 Vrms, 50 Hz Input Protection:
Patented Input Fuse Protection Output Specifications
+12V Rails: 1 Output Voltage
+3.3V DC
+5V DC
+12V1 DC
-12V DC
+5Vsb DC (Standby) Output Current
24A at +3.3V DC
15A at +5V DC
32A at +12V1 DC
0.3A at -12V DC
3.0A +5Vsb DC Standby Output Protection
Complete OVP, OCP, SCP, OPP, UVP Protection Item Dimension (L"xW"xH")
5.51 x 5.9 x 3.39
Weight
5.60 lb
Warranty Information
5 Years
