AS-2023US-TR4 - Supermicro

Motherboard
H11DSU-iN
Processor/Chipset
CPU
Dual AMD EPYC^TM 7001/7002 series Processors ( Board revision 2.x required)
Socket SP3
Supports CPU TDP 225W / cTDP up to 240W
Cores
Up to 32 Cores (Board revision 1.x + 7001 Processors)
Up to 64 Cores (Board revision 2.x + 7002 Processors)
Chipset
System on Chip (SoC)
System Memory
Memory Capacity
32 DIMM slots
Supports up to 4TB Registered ECC DDR4 2666MHz SDRAM (7001 Processors)
Supports up to 8TB Registered ECC DDR4 3200MHz SDRAM (Board revision 2.x required + 7002 Processors)
8-channel memory bus
Memory Type
DDR4 2666 MHz Registered ECC, 240-pin gold-plated DIMMs (7001 Processors)
DDR4 3200 MHz Registered ECC, 240-pin gold-plated DIMMs (Board revision 2.x required + 7002 Processors)
DIMM Sizes
4GB, 8GB, 16GB, 32GB, 64GB, 128GB, 256GB ( Board revision 2.x required + 7002 Processors)
Memory Voltage
1.2V
Error Detection
Corrects single-bit errors
Detects double-bit errors (using ECC memory)
On-Board Devices
SATA
SATA3 (6 Gbps)
IPMI
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
ASPEED AST2500 BMC
Network Controllers
Provided via Ultra Riser Card
VGA
ASPEED AST2500 BMC
Expansion Slots
2U
1 PCI-E 3.0 x16 slot (FH, 10.5" L)
5 PCI-E 3.0 x8 slots (FH, 9.5" L)
1 PCI-E 3.0 x8 slot (LP)
1 PCI-E 3.0 x8 (internal LP)
Input / Output
SATA
12 SATA3 (6 Gbps) ports
LAN
Quad Gigabit LAN ports
1 RJ45 Dedicated IPMI LAN port
USB
3 USB 3.0 ports (2 rear + 1 Type A)
VGA
1 VGA port
SAS
12 SAS3 ports support via optional Add-on Card
NVMe
4 NVMe support with optional cables
Others
1 COM port (rear)
2 SATA DOM power connector
TPM 1.2 header
System BIOS
BIOS Type
AMI 128Mb SPI Flash EEPROM
BIOS Features
Plug and Play (PnP)
DMI 2.3
PCI 2.2
ACPI 5.1
USB Keyboard Support
SMBIOS 3.1.1
Chassis
Form Factor
2U
Model
CSE-829U2TS-R1K62P-T
Front Panel
Buttons
Power On/Off button
System Reset button
LEDs
Power LED
Hard drive activity LED
2x Network activity LEDs
System Overheat LED / Fan fail LED / UID LED
Drive Bays
Hot-swap
12 hot-swap 3.5" Drive Bays:
12 SATA3 by default
Optional Drive Support: 8 SAS3 + 4 SAS3/NVMe
2 rear hot-swap 2.5" drive bays
Backplane
HDD Backplane
Supports 12 SATA3 or 8 SATA3 + 4 NVMe or 12 SAS3 HDD
System Cooling
Fans
4 heavy-duty PWM fans with optimal fan speed control
Power Supply
1600W Redundant Power Supplies with PMBus
Total Output Power
1600W/1000W
Dimension (W x H x L)
73.5 x 40 x 203 mm
Input
100-127Vac / 13 - 9A / 50-60Hz
200-240Vac / 10 - 8A / 50-60Hz
+12V
Max: 83.3A / Min: 0A (100-127Vac)
Max: 133A / Min: 0A (200-240Vac)
12Vsb
Max: 2.1A / Min: 0A
Output Type
25 Pairs Gold Finger Connector
Certification
Titanium Level
PC Health Monitoring
CPU
Monitors CPU Core Voltages, +12V, +3.3V, +5V, +5V standby, 3.3V standby, VBAT
CPU switching voltage regulator
FAN
Up to 8-fan status tachometer monitoring
Up to eight 4-pin fan headers
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors
Temperature
Monitoring for CPU and chassis environment
CPU Thermal Trip Support
Thermal control for 8x Fan connectors
I²C Temperature Sensing Logic
LED
CPU / System Overheat LED
Other Features
Chassis Intrusion Detection
Chassis Intrusion Header
Operating Environment / Compliance
RoHS
RoHS Compliant
Environmental Spec.
Operating Temperature:
10^oC to 35^oC (50^oF to 95^oF)
Non-operating Temperature:
-40^oC to 70^oC (-40^oF to 158^oF)
Operating Relative Humidity:
8% to 90% (non-condensing)
Non-operating Relative Humidity:
5% to 95% (non-condensing)
Item Dimension (L"xW"xH")
29 x 18 x 4
Weight
72.00 LB
Warranty Information
1 year
