Technical Specifications
HARDWARE FEATURES Interface
4 10/100/1000Mbps LAN Ports,
1 10/100/1000Mbps WAN Port
1 USB 3.0 Port + 1 USB 2.0 Port Button
Wireless On/Off Button
Power On/off Button
LED On/off Button
WPS Button
Reset Button Antenna
8 high-performance antennas External Power Supply
12V/5A WIRELESS FEATURES Wireless Standards
IEEE 802.11ac/n/a 5GHz
IEEE 802.11b/g/n 2.4GHz Frequency
2.4GHz and 5GHz Signal Rate
5GHz Band1: Up to 2167Mbps
5GHz Band2: Up to 2167Mbps
2.4GHz: Up to 1000Mbps Reception Sensitivity
5GHz:
11a 6Mbps: -94dBm
11a 54Mbps: -76dBm
11ac HT20 (MCS8): -68dBm 11ac HT20 (MCS11): -61dBm
11ac HT40 (MCS9): -64dBm, 11ac HT40 (MCS11): -57dBm
11ac HT80: -60dBm
2.4GHz
11g 54M: -77dBm
11n HT20 (MCS8): -73dBm, 11ac HT20 (MCS11): -63dBm
11ac HT40 (MCS9): -67dBm, 11ac HT40 (MCS11): -62dBm Wireless Functions
Enable/Disable Wireless Radio, WMM, Wireless Statistics Wireless Security
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption Transmission Power
CE:
<20dBm(2.4GHz)
<23dBm(5.15GHz to 5.35GHz)
<23dBm(5.47GHz to 5.725GHz)
FCC:
<30dBm Guest Network
2.4GHz guest network 1
5GHz guest network 2 SOFTWARE FEATURES Quality of Service
WMM, Bandwidth Control WAN Type
Dynamic IP/Static IP/PPPoE/
PPTP(Dual Access)/L2TP(Dual Access) Management
Access Control
Local Management
Remote Management DHCP
Server, Client, DHCP Client List,
Address Reservation Port Forwarding
Virtual Server, Port Triggering, UPnP, DMZ
