Product Overview
AC15 comes with the next generation 11ac Wi-Fi standard, offering total data transfer speeds up to 1.9Gbps. With 1.3Gbps over the clearer 5GHz frequency, and 600Mbps using two wireless chips to maximize performance over the 2.4GHz frequency, your whole home will get excellent wireless coverage. Ultra-fast 1GHz dual-core CPU function as a great 'heart' for fast, stable and responsive performance with Wi-Fi, Ethernet and USB devices. The outstanding Gigabit WiFi and Gigabit wired connections are ideal for bandwidth sensitive applications like streaming With AC15 you get a super-fast, high performance connected home.
Technical Specifications
Internet Connection Type
Dynamic IP, Static IP, PPPoE
StandardProtocol
IEEE 802.11ac/a/n 5GHz, IEEE 802.11b/g/n 2.4GHz
Interface
1x10/100/1000Mbps WAN, port 3x 10/100/1000Mbps LAN ports, 1x USB3.0 port
Antenna
3x3dBi external dual band antennas
Frequency
Works over 2.4G and 5G concurrently
LED
1xPower, 1xInternet, 3xLAN, 1x5G, 1x2.4G, 1xWPS, 1xUSB, 1xSYS
Button
1xPower on/off, 1xWiFi on/off, 1x Reset button,1x WPS button
Button
1xPower on/off, 1xWiFi on/off, 1x Reset button,1x WPS button
Power Output
DC 12V2.5A
Item Dimension (L"xW"xH"):
13 x 10.3 x 3
Weight:
2.27lb
Warranty Infotmation
1 Year
