Msi 919-98H1-03S Motherboard 919-98H1-02S MS-98H1 Core i7i/i5/i3 LGA1150 H81 DDR3/DDR3L SATA USB Mini-ITX Retail

CPU
4th Gen Intel Desktop Haswell/Haswell refresh Core i7/i5/i3/Pentium/Celeron Processor

Frequency
Depends on CPU

L2 Cache
Depends on CPU

CPU Type
Socket (LGA 1150)

Chipset
Intel Q87 Express

BIOS
AMI

Memory
Dual-channel DDR3/DDR3L 1066/1333/1600MHz

Max. Capacity
Up to 16GB

Socket
2 x 204-pin SO-DIMMs

Display
Intel HD Graphics

Graphic Memory
Shared system memory up to 1.7 GB SDRAM

LVDS
N/A

eDP
N/A

VGA
2

DVI
1 (DVI-D)

HDMI
1

DisplayPort
N/A

Multiple Display
3 independent displays (Q87 SKU)

Display Interface
VGA1 up to 1920 x 1080
VGA2 up to 1920 x 1080
DVI-D up to 1920 x 1200
HDMI up to 1920 x 1200

Ethernet
4 x Intel I210-AT GbE LAN
2 x Intel I211-AT GbE LAN (Optional by SKU)

Audio
Realtek ALC887 HD Audio Codec

Super I/O
Fintek F81866D

Watchdog Timer
255-level Watchdog Timer

Smart Fan
Yes

TPM
Pin header

USB
2 x USB 3.0 (rear)
6 x USB 2.0 (4 x rear, 2 x internal)

Serial
10 x COM (COM1 to 10: internal)
COM1: RS-232/422/485, 0V/5V/12V
COM2: RS-232/422/485, 0V/5V/12V
COM3 to 6: RS-232, 0V/5V/12V
COM7 to 10: RS-232, 0V/5V/12V (optional by SKU)

Parallel
N/A

PS/2
1

GPIO
8-bits (4 x GPI, 4 x GPO), 5V

Expansion Slot
PCIe x 16 : 1
PCIe x 4 : N/A
PCIe x 1: N/A
PCI : N/A
Mni-PCIe : 1 x Full-size (W/ mSATA), 1 x Half-size

Storage
SATA : 2 x SATA 3.0
IDE : N/A
eSATA : N/A
CFast : N/A
mSATA : 1
CompactFlash : N/A

Power Supply
DC : N/A
ATX : ATX-Power 24P, 12V-4P

Operating Temperature
-10 to 60^oC

Operating Humidity
10 to 90 percent, non-condensing

Storage Temperature
-20 to 80^oC

Storage Humidity
10 to 90 percent, non-condensing

Form Factor
170mm x 170mm (Mini-ITX)

Item Dimension (L inchxW inchxH inch)
20 x 17 x 17

Weight
35.00lb

Warranty Information
N/A
