6812-32X-O-AC-F-US - Edgecore Networking Edgecore 6812-32X 32-Port 40GbE QSFP+ Switch

Special Order
Ships in 1-2 weeks
Condition: New

$4,372.34  $5,902.66
Need 10+? Request a volume quote
 Free Shipping for this Item

Product Overview

The Edgecore 6812-32X is a high-performance 32-port 40GbE QSFP+ switch, designed for data center and enterprise applications. It features advanced functionalities to meet the demands of high-speed data transfers and low-latency communication in modern networks.

Technical Specifications

  • Ports: 32 QSFP+ fixed ports (40 GbE or 4 x 10 GbE per port)
  • Switch Capacity: 32 x 40 GbE
  • Management Ports: 1 x RJ-45 serial console, 1 x RJ-45 100/1000BASE-T management port, 1 x USB Type A storage port
  • Switch Silicon: Broadcom BCM56860 Trident II+ 1.28 Tbps
  • CPU: Intel Atom C2538 quad-core 2.4GHz x86 processor
  • Memory: 8 GB SO-DIMM DDR3 RAM with ECC, 16MB SPI flash, 8GB NAND flash, optional mSATA SSD
  • Performance: Switching capacity of 1.28 Tbps full duplex, forwarding rate of 1.44 Bpps, and supports jumbo frames up to 9216 Bytes
  • Supported Optics: Various cabling options, including 40GBASE-SR4 and 40GBASE-LR4, providing flexibility for connectivity
  • Physical Specs: Redundant hot-swappable fans, operating temperature range of 0°C to 40°C, and operating humidity of 5% to 95%
  • Software Compatibility: Supports Open Network Install Environment (ONIE) and various network operating systems (NOS)
  • Power: Dual redundant, load-sharing PSUs with 370 W max power, and 93% efficiency
  • Regulatory Compliance: CE Mark, FCC, and RoHS-6 compliant, with stringent environmental testing
  • Dimensions: 27 x 23 x 7 inches
  • Weight: 27 lbs
  • Warranty: 1 Year

Product Details

  • Manufacturer:
  • Model Number:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • EDGECORE NETWORKING
  • 6812-32X-O-AC-F-US
  • 662698607642
  • New
  • 27 lbs
  • 27 X 22 X 6
  • May 30, 2026
  • Jul 24, 2020
Product Identifiers: Brand: Edgecore Networking • Part #: 6812-32X-O-AC-F-US • UPC: 662698607642 • Category: Graphics Cards
