Condition: New
| Ports | |
|---|---|
| Switch Ports | 48 x RJ-45 Copper each supporting 10GbE, 1GbE or 100Mbps |
| Key Components | |
| Switch Silicon | Broadcom BCM56864 Trident2+ 720Gbps |
| CPU Modules | AS5812-54T: Intel Atom C2538 quad-core 2.4GHz x86 processor |
| Performance | |
| Wire Speed Forwarding | L2 and L3 |
| Switching Capacity | 720 Gbps |
| Forwarding Rate | 1 Bpps |
| MAC Addresses | 320 K |
| VLAN IDs | 4 K |
| L3 Routes | IPv4 64K, IPv6 20K |
| Packet Buffer Size | 12MB shared buffer pool |
| Latency (RFC2544) | 720 ns (L2/L3, cut thru, full line rate) |
| Supported Optics and Cables | RJ45 Copper ports: |
| 40GBASE-SR4 | Up to 100 m over OM3 MMF, 150 m over OM4 MMF |
| 40GBASE-SR4 to 6 x 10GBASE-SR | 100 m over OM3, 150 m OM4 |
| 40GBASE-LR4 | Up to 10km over SMF |
| Physical and Environmental | |
| Fans | hot-swappable 4+1 redundant fans |
| Operating Temperature | 0oC to 40oC (32oF to 104oF) |
| Storage Temperature | -40oC to 70oC (-40oF to 158oF) |
| Operating Humidity | 5% to 95% non-condensing |
| LEDs | |
| 10G SFP+ Port LEDs | Link Speed, Link Status, Activity |
| 40G QSFP Port LEDs | Link Status, Activity for 40G status |
| 40G QSFP Breakout LEDs | set of 24 LEDs, 4 per QSFP port, show Link, Status, Activity 10G links with 4x10G breakout |
| Ethernet Management Port LED | Link Status, Activity |
| Console Port LED | Link Status |
| System LEDs | PSU1, PSU2, Diagnostic, Fans, Locator |
| Software | Open Network Install Environment (ONIE) software installer |
| Power | |
| PSUs | 2 redundant, load-sharing, hot-swappable AC, |
| Input Voltage | 90 to 264 VAC at 50-60 Hz. -48 to -72 VDC. |
| Input Current | Max 6A 100/120VAC, 3A 200/240VAC, 10A -72 VDC |
| PSU Efficiency | Up to 93% for AC PSUs |
| Maximum Power Consumption | 348 W |
| Item Dimension (L inchxW inchxH inch) | 18 x 19 x 2 |
| Weight | 23.90 lb |
| Warranty Information | 3 Years |
