Technical Specifications
Planar Part Number
997-7460-00
Technology
Commercial-grade direct view LCD
Diagonal
55 inches
Aspect Ratio
16:9 Native Resolution Panels
1920 x 1080
Tiled Bezel Width
3.7 mm
Bezel Width
N/A
Brightness (typ)
800 cd/m or nits Response Time (typ)
8 ms
Contrast ratio (full field)
3500:1
Full viewing angle
178
Backlight life (1/2 brightness)
50,000 Hrs Mounted depth
3.6" wall to front of screen
Acoustic noise
Fanless operation
Heat load
628 BTU per hour at 500 nit
Backlight control
Individual and wall control Backlight sensing and reporting
At display level
Display module position sensing
Auto-sensing integrated
Power Consumption (max)
231 watts (typical)
Power supply voltage
100-230V AC 10%, 50 to 60 Hz Power status
Diagnostics LEDs, health monitoring and alerts
Safety regulations
Complies with EN60950, FCC Class A, CISPR22/85, CE, EU RoHS Data Inputs
4 HDMI inputs, 1 DisplayPort input
Control
IR Remote, RS232, Ethernet (optional)
Touch Options
Clarity Matrix MultiTouch Kits Item Dimension (L"xW"xH"):
47.84 x 27.01 x 3.6
Weight:
150 lb
Warranty Information:
3-Years
