Technical Specifications
PANEL
Panel Technology:IPS
Aspect Ratio:16 : 9
Native Resolution:1920 x 1080 (FHD)
Brightness:700cd/m2
Contrast Ratio:1,300:1
Dynamic CR:500,000:1
Viewing Angle (H x V):178o/178o
Surface Treatment:Hard Coating (3H), Anti-Glare Treatment of the Front Polarizer (Haze 10%)
Orientation:Portrait and Landscape
Panel Size:49 inch class (48.5 inch diagonal)
Pixels (H x V x 3):6,220,800
Response Time:8ms (G to G BW) Typical
Color Depth:1.07 Billion
Lifetime:50,000 Hrs min.
Operation Hours:24 Hr
Color Gamut:72% INPUT
Audio:Yes
HDTV Formats:HDMI : 720p, 1080i, 1080p
HDMI:Yes
DVI:Yes
Digital:Yes
DP:Yes CABINET
Bezel Color:Black
Bezel Width:7.4mm (T/L/R/U even)
VESA Compatible:400mm x 400mm
Temperature Sensor:Yes SPECIAL FEATURES
Time Sync clock:Yes
PM Mode:Yes
Time Sync Clock:Yes
Holiday Schedule:Yes
Local Auto Time:Yes
HDMI-CEC:Yes
Limited Mode:Input source change, Menu Display, OSD Display
Power on Default:Input source, A/V Setting, Aspect Ratio
Wake on LAN:Yes
Lock Mode:USB
Fail Over:USB, RGB, DVI, HDMI
SuperSign Server Setup:Player name, Server IP setting, Server IP Status
Power On Status:Standard, PWR, LST
Language: (OSD/ USB Playback)English, French, German, Spanish, Italian, Korean , Chinese (Simplified), Chinese (Original), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Portuguese (Europe), Dutch, Czech, Greek
Tile Mode:Yes (Up to 15x15)
Natural Mode at Tile Mode:Yes
Auto Brightness Sensor:Yes
Contents Scheduling:USB
Source Selection:DVI-D, HDMI, Display Port, USB, OPS,RGB
Brightness / Contrast / Backlight:Yes
Position / Size:Yes
Auto Config / Phase:Yes
Input Label (PC/DTV):Yes (PC/DTV)
Advanced:Dynamic Contrast, Dynamic Color, Color Gamut, Skin Color, Sky Color, Grass Color, Gamma
Time:Clock, On/Off Time, Auto Off, Automatic Standby
Key Operation:IR operation, Local key operation
Calibration mode:Yes
USB Cloning:Logo image download, EzDownload, Sent to USB, Receive from USB
Easy Brightness Control:Yes
Content scheduling:USB
ISM Method:Normal, White Wash, Color Wash, Orbiter, inversion, Washing Bar, User image
DPM Wake Up:Yes
File Play with USB:Yes
Wi-Fi:Dongle Ready
DPM Select:Yes
Wake On LAN:Yes
Frameware Update (LAN):Yes
Power On Delay:0 - 255
No Signal Image (Up to 5MB):Yes
Power On Default:Input source, A/V Setting, Aspect Ratio
Intelligent Auto:Yes
SetID Setup:Manual, Auto
Local Time Auto Setting:Yes
Still Image:Yes
OPS PC Power Control:Sync On, Sync On/Off, Disable ENVIRONMENT CONDITIONS
Operation Temperature:32 oF to 104 oF
Operation Humidity:10 % to 80 % VPOWER
Power Type:100-240V, 50/60Hz
Power Supply:Built-In Power POWER CONSUMPTION
DPM:0.7W (DP)
Power Off:0.5W
Typical:125W OUTPUT
Audio:Yes
External Speaker Out:Yes (L/R)
RS232C:Yes
DP Out:Yes AUDIO
Balance:Yes
Audio Power:20W (10W x 2) for External Speaker
Sound Mode:Standard, News, Music, Cinema, Sport, Game
Clear Voice II:Yes
Virtual Surround:Yes
Equalizer:Yes CERTIFICATION
Safety / EMC / ErP:UL / cUL / CB / TUV / KC / FCC Class "A" / CE / KCC / Yes MEDIA PLAYER COMPATIBILITY
External Media Player Attatchable:Yes (MP500/MP700)
OPS Type Compatible:Yes ACCESSORIES
Basic:Remote Controller (include battery 2 each), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, IR Receiver
Optional:SP-2100 (External Speaker), ST-200T, LSW440S, AN-WF500 (WiFi USB Dongle), KTOPSA (OPS Kits), KT-SP0 (Pixel Sensor) SOFTWARE COMPATIBILITY
SuperSign Elite-c:Yes
SuperSign-w lite:Yes Item Dimension (L inchxW inchxH inch)
48 x 30 x 6 Weight
53.00lb Warranty Information
3 Year Limited
