Evga 220-G5-0650-X1 SuperNOVA 220-P2-0650-X1 650 P2, 80+ PLATINUM 650W, Fully Modular, ECO Mode, 10 Year Warranty, Inclu

CABLE LENGTH
ATX Cable
1x 600mm (m)
EPS Cable
1x 700mm (m)
PCIe Cable
1x 700mm, 1x 700mm, 850mm (m)
SATA Cable
2x 550mm, 650mm, 750mm (m)
Four-Pin Peripheral Cable
1x 550mm, 650mm, 750mm, 850mm (m)
Floppy Adapter
1x 100mm
AC Power
1x 1500mm (m)
Modular Cable Type
Full
CONNECTOR QUANTITY
24 Pin ATX
1x 24pin (20+4)
EPS (CPU)
1x 8pin (4+4)
PCIe
3x 8pin (6+2)
SATA
6x
Four-Pin Peripheral
4x
Floppy
1x
POWER SPECS
AC Input
100 - 240 VAC, 12-5A, 50/60 Hz
Rail
+3.3V
Max Output
24A
120W
Rail
+5V
Max Output
24A
120W
Rail
+12V
Max Output
54.1A
649.2W
649.2W
Rail
+5Vsb
Max Output
3A
15W
Rail
-12V
Max Output
0.5A
6W
Total
650W at +50C
ADDITIONAL DETAILS
Operating Temperature
0^o to 50^oC
Japanese Capacitors
100%
ECO Mode
Yes
MTBF
100,000 Hours
Approvals
TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
Compliance with ErP Lot 3 2014 Requirement
Fan Size / Bearing
135mm Fluid Dynamic Bearing
Item Dimension (L"xW"xH")
12 x 5 x 9
Weight
4.90 LB
Warranty Information
10 Years
