Evga 210GQ0650V1 650 GQ - power supply - 650 Watt

Special Order
Ships in 1-2 weeks
Condition: New

$159.80  $215.73
Need 10+? Request a volume quote
 Free Shipping for this Item

Product Overview

EVGA 650 GQ Power Supply. Ready for 4th Generation Intel Core Processors (C6/C7 Idle Mode). Introducing the latest in the EVGA power supply lineup, the GQ series. These power supplies take some of the best features from EVGA's award winning power supplies, like EVGA ECO fan mode for near silent operation, Japanese Capacitor Design and a highly efficient design, at an excellent value. These new power supplies are 80 Plus Gold rated and offer an outstanding 5 Year Warranty that's backed by world class EVGA support. 80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC 240VAC) efficiency or higher under typical loads Highest quality Japanese brand capacitors ensure long-term reliability. NVIDIA SLI & AMD Crossfire Ready. Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection).

Technical Specifications

Specifications

  • Mfr Part Number: 210-GQ-0650-V1
  • Features:
    • 80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC~240VAC) efficiency or higher under typical loads
    • NVIDIA SLI & AMD Crossfire Ready
    • 5 Year Warranty and unparalleled EVGA Customer Support
    • Modular Design to reduce clutter and improve airflow
    • 100% Japanese Capacitors ensure long-term reliability
    • Active Clamp +DC to DC design for efficient operation
    • EVGA ECO Intelligent Thermal Control System elminates fan noise at low to medium loads
    • Whisper Silent with 135mm Fluid Dynamic Bearing Fan
    • Active Power Factor Correction (PFC)
  • Maximum Power: 650 W
  • Input:
    • Voltage: 100 ~ 240 VAC
    • Current: 10 A
    • Frequency Range: 50 ~ 60 Hz
  • Type: ATX12V / EPS12V
  • Power Factor Correction: Active PFC
  • Efficiency: 90% (115VAC) / 92% (220VAC~240VAC) or Higher Typical
  • MTBF: 100,000 hours
  • Fan: 135mm Fluid Dynamic Bearing
  • Output: +3.3V @ 24A, +5V @ 24A, +12V @ 54A, +5VSB @ 3A, -12V @ 0.5A
  • Connectors: 1x 24pin ATX Main Connector, 2x 8pin (4+4) EPS (CPU) Power Connector, 4x 8pin (6+2) PCI-Express Connectors, 9x SATA Connectors, 3x 4Pin Peripheral Connectors, 2x Floppy Connectors
  • Approvals: TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS Compliance with ErP Lot 6 2013 Requirement
  • Dimensions (WxLxH): 150.0 x 165.0 x 85.0 mm
  • Weight: 7.0 lbs

Product Details

  • Manufacturer:
  • Model Number:
  • ASIN:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • EVGA
  • 210GQ0650V1
  • B017HA3SQ8
  • 843368035709
  • New
  • 22 lbs
  • 13 X 6 X 9
  • Apr 25, 2026
  • Aug 24, 2021
Product Identifiers: Brand: Evga • Part #: 210GQ0650V1 • UPC: 843368035709 • ASIN: B017HA3SQ8 • Category: Monitor Supplies
