SKU: E0TVV7BWJH |  Mfg. Part: 206-053S  | UPC: 602290201428  |
 1 Reviews  |     Share

Paneltronics 206-053S Breaker 15 Amps A-Frame Magnetic Waterproof

Out of Stock
Condition: New

$31.57  $42.62
 Free Shipping for this Item

Product Overview

Panel Seal / Waterproof "A" Frame Magnetic Circuit Breakers

  • Branch AC or DC circuit breaker for Paneltronics electrical distribution panels
  • Meets all American Boat and Yacht Council (ABYC) Standards for non ignition protected circuit breakers
  • UL Recognized (UL 1077) for use in the U.S.A., and CSA Certified for use in Canada
  • Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)
  • Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)

Specifications

  • Handle Color: Metal with Silicon rubber seal
  • Maximum Amperage: 50 Amps
  • Maximum Voltage/AIC: 32 VDC/ 2,500 Amps with no Back-up Fuse (ABYC E-11.10.1.5.5)
  • Rated Switch Cycles: Rated Switch Cycles 10,000 actuations at rated current and voltage
  • Electrical Hardware Screw: 10-32 x 3/8" pan combo head (P/N 197-188)
  • Mounting Hardware: Hex nut 1/2-32 (supplied with circuit breaker)
  • Lockwasher: 1/2" internal tooth (supplied with circuit breaker)
  • Optional Boot: Black silicone rubber (P/N 048-015)














Product Details

  • Manufacturer:
  • Model Number:
  • ASIN:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • Country of Origin:
  • Paneltronics
  • 206-053S
  • B000OTJ800
  • 602290201428
  • New
  • 1 lbs
  • 3 X 3 X 3
  • Feb 19, 2026
  • Dec 21, 2021
  • UNITED STATES
Product Identifiers: Brand: Paneltronics • Part #: 206-053S • UPC: 602290201428 • ASIN: B000OTJ800

Paneltronics 206-053S Breaker 15 Amps A-Frame Magnetic Waterproof
