05-25688-00 - Lsi Logic 9302-16e 16PT SAS 12Gb s PCIE3 30W Host Bus Adapter sgl

Lifecycle
Active Host Bus Type
x16 Lane PCI Express 2.0 Devices Supported
1024 Non-RAID SATA/SATA Device Per Controller External Connectors
4 Mini-SAS HD SFF8644 Operating Temperature
0 C to 55 C Operating Voltage
+12V +/-8%, 3.3V +/-9% OS Support
Microsoft Windows, Linux (SuSE , Red Hat), Solaris, VMware , FreeBSD See the downloads page for details on versions The HBA supports Solaris 10 and Oracle provides a built in driver installation of an LSI driver is not required. For more information PCI Power
30W Cable Support
Passive Copper, Active Optical I/O Controller
2 SAS 3008 MTBF
>1,500,000 Hours Operating Humidity
5% to 90% Non-Condensing Brackets
Full Height Regulatory Certifications
Australia/New Zealand (AS/NZS 3548), Canada (ICES-003), EMC: Class B-US (CFR 47, P15B), Europe (EN55022/EN55024), Japan (V-3/02.04), Korea (N-B 2-0001-404), RoHS, Safety: EN60950, WEEE Data Transfer Rates
12Gb/s SAS-3 Compliant Item Dimension (L"xW"xH")
6 x 11 x 2

Weight
1.00 lb

Warranty Information
3 Years
