Technical Specifications
GPU
2304 Stream Processors
14 nm FinFET
4th Graphics Core Next (GCN)
1411 MHz Boost Engine Clock Memory
256 bit Memory Bus
GDDR5 Memory Type
2000 MHz, 8000 MHz Effective
8 GB Size BIOS Support
UEFI BIOS Displays
Maximum 5 Outputs Output
1 x DVI-D
2 x HDMI
2 x DisplayPort 1.4 Resolution
3840x2160 (120Hz) Pixel DisplayPort Resolution
2560x1600 (60Hz) Pixel Dual Link DVI Resolution
38402160p (60 Hz) HDMI Resolution API
OpenGL 4.5
OpenCL 2.0
DirectX 12
Shader Model 5.0 Feature
AMD CrossFire
FreeSync Technology
AMD Eyefinity
Quad HD Display (4K2K Support)
Dual BIOS
AMD Liquid VR Technology
AMD Xconnect ready
DirectX 12 Optimized
Radeon VR ready Premium
HDR Ready
Frame Rate Target Control
NITRO Fan Check
NITRO Quick Connect system
NITRO Glow RGB LED
NITRO CoolTech(NCT)
NITRO Free Flow
Dual-X Cooling
NITRO Boost
Intelligent Fan Control III
Black Diamond Choke 4
Fuse protection
Precision fan control
Robust VRM Cooling
Radeon Chill
Radeon Relive Cooling Single fan
Dual-X fans
Two ball bearing Form Factor
2.2 Part Slot Occupied Power Consumption
<235W OS
Windows 10
Windows 7 System Requirement
500 Watt Power Supply (Suggestion)
1 x 8-pin AUX Power Connector
1 x 6-pin AUX Power Connector
Blue-ray / HD DVD playback requires Blu-ray / HD DVD drive.
1 x 6-pin AUX Power Connector
PCI Express 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with. Item Dimension (L inchxW inchxH inch)
13 x 9 x 3
Weight
4.00 lb
Warranty Information
2 years
