Technical Specifications
CABLE LENGTH
ATX Cable
1x 550mm
EPS Cable
1x 600mm
PCIe Cable
1x 550mm, 670mm
SATA Cable
2x 450mm, 570mm, 690mm
Four-Pin Peripheral Cable
1x 450mm, 570mm, 690mm + 810mm (Floppy)
AC Power
1x 1200mm (m)
Modular Cable Type
No
CONNECTOR QUANTITY
24 Pin ATX
1x
EPS (CPU)
1x 8pin (4+4)
PCIe
2x 8pin (6+2)
SATA
6x
Four-Pin Peripheral
3x
Floppy
1x
POWER SPECS
AC Input
100-240V-, 8-4A, 60/50Hz
Rail-Max Output
+3.3V-20A/120W
+5V-20A/120W
+12V-41.6A/500W
+5Vsb-3A/15W
-12V-0.3A/3.6W
Total
500W
ADDITIONAL DETAILS
Operating Temperature
0o to 30o C
Japanese Capacitors
No
ECO Mode
No
MTBF
100,000 Hours
Approvals
TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS Compliance with ErP Lot 3 2014 Requirement
Fan Size / Bearing
120mm Sleeve Bearing
Item Dimension (L"x W"x H")
8 x 7 x 7
Weight
4.33 LB
Warranty Information
3 years
