Technical Specifications
Image Sensor
1/2.8 2 Megapixel Exmor CMOS
Effective Pixels
1944(H)1092(V)
Horizontal Resolution
1000TVL
Scanning System
Progressive
Electronic Shutter Speed
1/1s to 1/30,000s Min. Illumination
Color: 0.05 Lux/F1.6, B/W: 0.005Lux/F1.6
S/N Ratio
More than 55dB
Resolution
25/30fpsat1080P, 25/30/50/60fpsat720P
Video Output
1channel BNC HDCVI high definition video output Day/Night
Auto(ICR) / Color / B/W
Backlight Compensation
BLC / HLC / DWDR (Digital WDR)
White Balance
Auto, ATW, Indoor, Outdoor, Manual
Gain Control
Auto / Manual
Noise Reduction
2D/3D Privacy Masking
Up to 24 areas
Digital Zoom
16x
Focal Length
5.1 mmto61.2mm (12x Optical zoom)
Max Aperture
F1.2 to F2.1
Focus Control
Auto / Manual
Angle of View
H: 51.3 to 4.64 Close Focus Distance
100 mm to 1000 mm
Pan/Tilt Range
Pan: 0 to 360 endless Tilt: -2 to 90, auto flip 180
Manual Control Speed
Pan: 0.1 to 300/s Tilt: 0.1 to 120/s
Preset Speed
Pan: 300/s Tilt:200/s
Preset
80(DH-SD) , 255(Pelco-P/D) PTZ Mode
5 Pattern, 8 Tour, 5 Auto Scan, Auto Pan
Speed Setup
Human-oriented focal length/ speed adaptation
Power up Action
Auto restore to previous PTZ and lens status after power failure
Idle Motion
Activate Preset/ Pan/ Scan/ Tour/ Pattern if there is no command in the specified period
Protocol
DH-SD, Pelco-P/D (Auto recognition)
Audio Interface
1 channel In RS485
1
Alarm
2 / 1 channel In / Out
Power Supply
AC24V/1.5A (+/-10%)
Power Consumption
10W, 19W(Heater on) 10W
Ingress Protection
IP66
Vandal Resistance
No Item Dimension (L"xW"xH"):
10.00 x 10.00 x 10.20
Weight:
6.9 lb
Warranty Information:
2 Years
