Tyan S7070GM2NR Motherboard S7070GM2NR E5-2600v3/v4 C612 2xLGA2011 SATA PCI Express SSI EEB Retail

Processor
Socket Type / Qty: LGA2011 / (2)
Supported CPU Series: Intel Xeon Processor E5-2600 v3/v4 product families
Thermal Design Power (TDP) wattage: Max up to 160W
System Bus: Up to 9.6/ 8.0/ 6.4 GT/s with Intel QuickPath Interconnect (QPI) support Chipset
PCH: Intel C612 Memory
Supported DIMM Qty: (8)+(8) DIMM slots
DIMM Type / Speed: RDIMM DDR4 2400/2133/1600 / LRDIMM DDR4 2400/1866 / LRDIMM 3DS DDR4 2400/1866 (Up to 2400 speed support only w/E5-2600 v4)
Capacity: Up to 512GB RDIMM/ 1,024GB LRDIMM/ 2,048GB LRDIMM 3DS Follow latest Intel DDR4 Memory POR
Memory channel: 4 Channels per CPU
Memory voltage: 1.2V Expansion Slots
PCI-E: (1) PCI-E Gen3 x8 slot(number 1,CPU1)
(1) PCI-E Gen3 x16 slot(number 2,CPU1)
(1) PCI-E Gen3 x16 slot(number 4,CPU0)
(1) PCI-E Gen3 x16 slot(number 6,CPU0) LAN
Port Qty: (2) GbE ports (1 port shared with IPMI)
Controller: Intel I350-AM2 Storage
SATA Connector: (6) SATA-III + (4) SATA ports by (1) mini-SAS connector
Controller: Intel C612
Speed: 6.0 Gb/s
RAID: RAID 0/1/10/5 (Intel RST) Graphic
Connector type: D-Sub 15-pin
Resolution: Up to 1920x1200
Chipset: Aspeed AST2400 Input /Output
USB: (4) USB3.0 ports (2 at rear, 2 via cable) / (5) USB2.0 ports (1 stack-up ports, 1 type A header, 2 via cable)
COM: (1) header
VGA: (1) D-Sub 15-pin VGA port
RJ-45: Total (2) GbE ports, (1) shared with IPMI
SATA: (6) SATA-III + (4) SATA ports by (1) mini-SAS connector
Power: SSI 24-pin + 8-pin + 8-pin power connectors / (1) 4 PIN power connector for PCI-E System Monitoring
Chipset: Aspeed AST2400
Fan: Total (7) 4-pin headers / Total (1) 2 x 10-pin headers
Temperature: Monitors temperature for CPU memory system environment
Voltage: Monitors voltage for CPU, memory, chipset power supply
LED: Over temperature warning indicator / Fan PSU fail LED indicator
Others: Watchdog timer support Server Management
Onboard Chipset: Onboard Aspeed AST2400
AST2400 IPMI Feature: IPMI 2.0 compliant baseboard management controller (BMC) / Supports storage over IP and remote platform-flash / USB 2.0 virtual hub
AST2400 iKVM Feature: 24-bit high quality video compression / 10/100 Mb/s MAC interface BIOS
Brand / ROM size: AMI / 16MB
Feature: Hardware Monitor / SMBIOS 2.7/PnP/Wake on LAN / PXE boot support / ACPI 3.0/ACPI sleeping states S4,S5 Physical Dimension
Form Factor: SSI EEB
Board Dimension: 12 inch x 13 inch (305x330mm) Operating System
OS supported list: Please refer to our Intel OS supported list. Regulation
FCC (DoC): Class A
CE (DoC): Yes Operating Environment
Operating Temp.: 10^oC to 35^oC (50^oF to 95^oF)
Non-operating Temp.: - 40^oC to 70^oC (-40^oF to 158^oF)
In/Non-operating Humidity: 90%, non-condensing at 35^oC RoHS
RoHS 6/6 Compliant: Yes Package Contains
Motherboard: (1) S7070 Motherboard
Manual: (1) Quick Installation Guide
Installation CD: (1) TYAN installation CD Item Dimension (L inchxW inchxH inch)
NA

Weight
3.00lb

Warranty Information
3 Years
