Tyan S5630GMRE Motherboard S5630GMRE CX S5630 Single Intel Xeon Scalable C621 LGA3647 DDR4 PCIE Retail

Processor
Qty / Socket Type:(1) LGA3647
Supported CPU Series:Intel Xeon Scalable Processor
Thermal Design Power (TDP) Wattage:Max up to 205W
Chipset
PCH:Intel C621
Memory
Supported DIMM Qty:(12) DIMM slots
DIMM Type / Speed:DDR4 RDIMM/RDIMM 3DS/LRDIMM/LRDIMM 3DS 2666
Capacity:Up to 384GB RDIMM/ 768GB LRDIMM/ 1,536GB RDIMM 3DS/LRDIMM 3DS Follow latest Intel DDR4 Memory POR
Memory channel:6 Channels
Memory voltage:1.2V
Expansion Slots
PCI-E:(1) PCI-E Gen3 x16 slot
Others:(1) PCI-E Gen3 x8 OCP 2.0 slots (conn.A+conn.B)
LAN
Qty / Port:(1) PHY
PHY:Realtek RTL8211E
Storage
NVMe:(2) PCI-E x8 SFF-8612 OCuLink connectors for (4) NVMe ports
SATA:Connector:(2) Mini-SAS HD (8-ports)
Controller:Intel C621
Speed:6.0 Gb/s
RAID:RAID 0/1/10/5 (Intel RSTe)
sSATA:Connector:(2) SATA-DOM / (1) Mini-SAS HD (4-ports)
Controller:Intel C621
Speed:6.0 Gb/s
RAID:RAID 0/1/10/5 (Intel RSTe)
Graphic
Connector type:D-Sub 15-pin
Resolution:Up to 1920x1200
Chipset:Aspeed AST2500
Input /Output
Others:(1) ID button
USB:(5) USB3.0 ports (2 at rear, 2 via cable, Type-A)
COM:(1) DB-9 COM Connector (at rear, COM1) + (1) Header (COM2)
VGA:(1) D-Sub 15-pin VGA port (at rear)
RJ-45:(1) GbE port dedicated for IPMI
Audio:Line-in, Line-out, Mic-in, Surround, Side surround, CEN/LFE at rear
Front Panel:(1) 2x12-pin SSI front panel header
SATA:(2) SATA/SATA-DOM connectors + (3) Mini-SAS (4-in-1) connectors
Power:ATX 24-pin + 8-pin power connectors
TPM (Optional)
TPM Support:Please refer to our TPM supported list.
System Monitoring
Chipset:Aspeed AST2500
Fan:Total (6) 4-pin headers
Temperature:Monitors temperature for CPU and memory and system environment
Voltage:Monitors voltage for CPU, memory, chipset and power supply
LED:Over temperature warning indicator / Fan and PSU fail LED indicator
Others:Watchdog timer support
Server Management
Onboard Chipset:Onboard Aspeed AST2500
AST2500 iKVM Feature:24-bit high quality video compression / Supports storage over IP and remote platform-flash / USB 2.0 virtual hub
AST2500 IPMI Feature:IPMI 2.0 compliant baseboard management controller (BMC) / 10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size:AMI / 32MB
Feature:Hardware Monitor / SMBIOS 3.0/PnP/Wake on LAN / Boot from USB device/PXE via LAN/Storage / User Configurable FAN PWM Duty Cycle / Console Redirection / ACPI sleeping states S4,S5 / ACPI 6.1
Regulation
FCC (DoC):Class A
CE (DoC):Class A
Operating Environment
Operating Temp.:10^o C to 35^o C (50^o Fto 95^o F)
Non-operating Temp.:- 40^o C to 70^o C (-40^o F to 158^o F)
In/Non-operating Humidity:90%, non-condensing at 35^o C
RoHS
RoHS 6/6 Compliant:Yes
Operating System
OS supported list:Please refer to our AVL support lists.
Package Contains
Motherboard:(1) S5630 Motherboard
Manual:(1) Quick Installation Guide
Installation CD:(1) TYAN Device Driver CD
Item Dimension (L inchxW inchxH inch)
12 x 11 x 1 Weight
3.00lb Warranty Information
3 Years
