Technical Specifications
1.Single External Mini-SAS Port
2.PCIe 2.0 x8 Host Interface
3.Supports RAID 5 and 6
4.Dual-Storage Modes: LTO Tape and RAID Arrays
5.Backward Compatible with HighPoint RAID HBA Host Interface:
PCIe 2.0 x8
Data Transfer Rate:
Up to 6Gb/s per channel
Device Ports:
1x External Mini-SAS port (SFF-8088) Devices Interface:
Mini-SAS, SATA
No. of Disk(s):
Directly supports up to 4 SAS/SATA HDD/SSD, up to 128 via SAS Expander RAID Levels:
RAID 0, 1, 5, 6, 10, 50 and JBOD
Backwards Compatibility:
backward compatible with single disks/RAID array created with HighPoint RAID HBA Dual-Storage Modes:
LTO Tape and RAID Arrays
System Support:
Mac and PC Systems with PCIe support O.S. Support:
Mac OS X 10.8.6 or greater and Windows 7 and 8. LTO Tape support requires Windows 8.1/8/7 or Linux Kernel 2.6 and later. RAID Suite:
User friendly Browser-based Management Interface Monitoring and Management Support:
SMTP, LED Status, Event Log
ROHS Compliant:
Yes Item Dimension (L"xW"xH"):
7.75 x 6.81 x 1.18
Weight:
0.41 lb
Warranty Information:
1 Year
