1 Available
Condition: New
Echonautics BT87H1KW 130-210kHz 1kW High CHIRP 12 deg Tilted Element
Model: BT87H1KW-12The Echonautics BT87H1kW is a low-profile thru hull CHIRP transducer designed to minimize drag and to perform at high speeds.
Thanks to the narrow beamwidth, it is excellent for pinpointing fish holding tight to reefs, wrecks, and other structures.
Specifications| Depth and Temperature | |
| Frequency | CHIRP 130 - 210 kHz |
| Tilt/deadrise | 12 deg tilted version: for 8 deg to 15 deg hull deadrise |
| Material | Bronze |
| RMS Power | 1 kW |
| Beamwidth | 13 deg to 8 deg @-3db |
| Depth | Max 304 m (1,000 ft) |
| Temp. sensor | NTC |
| Acoustic window | Urethane |
| Cable length | 9 m (30 ft) |
| Hole diameter | 87.6 mm (3.45 in) |
Sitex Marine Electronics BT87H1kW-12 Echonautics BT87H1kW-12 1kW 130-210kHz High CHIRP 0d Tilted Element Bronze TH
