Iei Technology PPC-F06B-BT-N1/2G/R-R10 IEI System PPC-F06B-BT-N1/2G/R-R10 5.7 inch Celeron N2807 2GB DDR3L Touch Windows

Display
LCD Size: 5.7 inch (4:3)
Brightness(cd/m2): 550
Max Resolution: 640(W) x 480(H)
Contrast Ratio: 800: 1
Backlight MTBF(hrs): 50000 System
CPU: Intel Celeron N2807
dual-core processor, 1.58GHz
SSD: mSATA I/O Interface
RAM: 2GB DDR3L 1600MHz on-board RAM (system max. 4GB, by MOQ300pcs)
I/O Ports and Switches: 1 x RJ-45 LAN port
1 x RS-232 COM port (DB-9 connector)
(RI/5V/12V)
1 x RS-422/485
2 x USB 3.0
2 x USB 2.0
1 x 9 V to 30 V DC lockable DC jack (2-pin)
1 x Audio port (line-out)
1 x Power switch Power adapter
9V to 30VDC Environment
Operating Temperature: -10^oC to 50^oC (14^oF to 122^oF)
Safety and EMC: CE and FCC Class A certified
Humidity: 10% to 95% (non-condensing)
Storage Temperature: -20^oC to 60^oC (-4^oF to 140^oF)
IP Level: Front IP 65 Physical Characteristics
Color: Black C
Mounting: Stand, panel mount, rack mount, VESA 75x75
Construction: Aluminum front bezel Expansion Slots
1 x Full-size PCIe Mini slot (with mSATA, PCIe/USB signal) LCD
LCD Color: 262K
Pixel Pitch (mm): 0.18mm x 0.18mm
Viewing Angle (H-V): 160^o / 140^o Touch Screen
4-wire resistive type flat touch window Touch Controller
PenMount DMC9000 I/O Interface
1 x AT/ATX Switch
2 x USB3.0
2 x USB2.0
1 x Reset Button
1 x Power In(9-30V Lockable power jack)
1 x RS-232(DB-9)
1 x Power Switch
1 x LAN(RJ-45)
1 x Audio(line-out)
1 x RS-422/485 Item Dimension (L inchxW inchxH inch)
10 x 8 x 3

Weight
1.96lb

Warranty Information
2 Years
