Technical Specifications
Main Processor
Intel Processors Operating System
LINUX IP Camera Input
32 channel Two-way Talk
1channel Input, 1channel Output, RCA Interface
2 HDMI (up to 38402160), 1 VGA Resolution
38402160, 19201080, 12801024, 1280720,1024768 Multi-screen Display
The 1st screen: 1/4/8/9/16/25/36 The 2nd screen:
1/4/8/9/16 OSD Camera title, Time, Video loss, Camera lock,Motion detection, Recording Compression
H.264/MJPEG Resolution
12Mp, 8Mp, 6Mp, 5Mp, 3Mp, 1080P, 1.3Mp, 720P etc. Record Rate
256Mbps Bit Rate
1 20Mbps Record Mode
Manual, Schedule(Regular(Continuous), MD(Video detection: Motion detection, Camera blank,Video loss), Alarm), Stop Record Interval
1120 min (default: 60 min), Pre-record: 130 sec, Post-record: 10300 sec Trigger Events
Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer Screen tips Video Detection
Motion Detection, MD Zones: 396(2218), Video Loss Camera Blank Alarm Input
16ch, low level effective, green terminal interface Relay Output
8ch, Relay contact(1A24VDC),NO/NC programmable green terminal interface Playback
128Mbps in Raid 5 mode 64Mbps in single HDD mode Search Mode
Time/Date, Alarm, MD Exact search(accurate to second), Smart search
